System And Components
473-4105 HOOD & GUARD GPS/N RBF1-20000
Group No: 473-4105 · Commonality
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 4I0118 | 1 HOOK AS | 3 | |
| 7Y2853 | 2 SPACER (13X38X5-MM THK) | 3 | |
| 1703016 | 3 SPACER (19X32X2-MM THK) | 15 | |
| 2447789 | 4 SPACER (19X38X3-MM THK) | 7 | |
| 2622603 | 5 SPACER (13.5X30X16-MM THK) | 7 | |
| 3272884 | 6 BRACKET AS | 1 | |
| 3272886 | 7 STRIKER AS | 2 | |
| 3272889 | 8 SHEET AS | 1 | |
| 3301306 | 9 DOOR GP-ACCESS (PUMP COMPARTMENT) | 1 | |
| 3335039 | 10 DOOR GP-ACCESS (AIR CLEANER, BATTERY) | 1 | |
| 3335045 | 11 DOOR GP-ACCESS (RADIATOR, AFCLR, HYD COOLER) | 1 | |
| 3361776 | 12 SUPPORT AS | 1 | |
| 3361777 | LINER | 1 | |
| 3374414 | 13 SUPPORT AS | 1 | |
| 3374455 | 14 SUPPORT AS | 1 | |
| 3374460 | 15 SUPPORT AS | 1 | |
| 3485409 | SEAL (16-DM) | ||
| 3374518 | 16 SUPPORT AS-ENCLOSURE | 1 | |
| 3374569 | 17 SHEET AS-SOUND SUPPRESSION | 1 | |
| 3374577 | 18 SHEET | 1 | |
| 3374578 | 19 SHEET AS-SOUND SUPPRESSION | 1 | |
| 3374604 | 20 SHEET | 1 | |
| 3374619 | 21 SHEET AS | 1 | |
| 3374621 | LINER | 1 | |
| 3374625 | 22 SHEET AS | 1 | |
| 5105444 | 23 COVER AS | 1 | |
| 4I7924 | WASHER (4.5X40X1.2-MM THK) | 2 | |
| 6P2216 | CAP (PUSH ON) | 2 | |
| 5105446 | SILENCER | 1 | |
| 3374659 | 24 SUPPORT AS | 1 | |
| 3432465 | 25 BUMPER | 5 | |
| 3490480 | 26 SUPPORT AS | 2 | |
| 3504649 | 27 BRACKET AS | 1 | |
| 3504655 | 28 SHEET AS | 1 | |
| 3485409 | SEAL (4-DM) | ||
| 3536598 | 29 SUPPORT AS-ENCLOSURE | 1 | |
| 3536599 | LINER | 1 | |
| 3536763 | 30 SUPPORT AS | 1 | |
| 5118272 | 31 BRACKET | 1 | |
| 3536771 | 32 SUPPORT AS-ENCLOSURE | 1 | |
| 3536782 | 33 SHEET AS-SOUND SUPPRESSION | 1 | |
| 3536786 | 34 SUPPORT AS | 1 | |
| 3536788 | 35 SUPPORT AS | 1 | |
| 3568950 | 36 SHEET AS | 1 | |
| 3361792 | INSULATION | 1 | |
| 3485409 | SEAL (8-DM) | ||
| 4984566 | 37 SHEET AS-SOUND SUPPRESSION | 1 | |
| 3568958 | 38 SUPPORT AS-ENCLOSURE | 1 | |
| 3569056 | 39 SHEET AS-SOUND SUPPRESSION | 1 | |
| 3569312 | 40 SHEET AS-SOUND SUPPRESSION | 1 | |
| 3569314 | LINER | 1 | |
| 3569344 | 41 SHEET AS-SOUND SUPPRESSION | 1 | |
| 3569345 | 42 SHEET AS-SOUND SUPPRESSION | 1 | |
| 3569396 | LINER | 1 | |
| 3569346 | 43 SHEET AS-SOUND SUPPRESSION | 1 | |
| 3569347 | 44 SHEET AS-SOUND SUPPRESSION | 1 | |
| 3569405 | LINER | 1 | |
| 3635692 | 45 SUPPORT AS | 1 | |
| 3667176 | 46 HOOD GP-ENGINE COMPARTMENT (HINGED) | 1 | |
| 3667211 | 47 SUPPORT AS | 1 | |
| 3667217 | 48 SPRING AS-GAS (ENGINE HOOD) | 1 | |
| 3719975 | 49 SHEET AS-SOUND SUPPRESSION | 1 | |
| 3743670 | 50 SUPPORT AS | 1 | |
| 3776721 | 51 SHEET AS | 1 | |
| 3776722 | LINER | 1 | |
| 3776723 | 52 SHEET AS-SOUND SUPPRESSION | 1 | |
| 3797363 | 53 SPRING | 1 | |
| 3797364 | 54 SUPPORT AS | 1 | |
| 3797366 | 55 SUPPORT AS | 1 | |
| 3922699 | 56 SUPPORT AS-SOUND SUPPRESSION | 1 | |
| 3938743 | 57 SHEET AS | 1 | |
| 4I7924 | WASHER (4.5X40X1.2-MM THK) | 4 | |
| 6P2216 | CAP (PUSH ON) | 4 | |
| 3374596 | SILENCER | 1 | |
| 3485409 | SEAL (1-DM) | ||
| 3938745 | 58 SHEET AS-SOUND SUPPRESSION | 1 | |
| 3938756 | 59 SUPPORT AS-SOUND SUPPRESSION | 1 | |
| 3938758 | 60 SUPPORT AS | 1 | |
| 4734128 | 61 SHEET AS | 1 | |
| 4733487 | LINER | 1 | |
| 4181598 | 62 SUPPORT AS | 1 | |
| 4336258 | 63 SUPPORT AS | 1 | |
| 4336263 | 64 HOOD GP-ENGINE (HINGED) | 1 | |
| 4360787 | 65 SHEET AS-SOUND SUPPRESSION | 1 | |
| 4382397 | 66 COVER AS-SOUND SUPPRESSION (FUEL, HYDRAULIC TANKS) | 1 | |
| 4458143 | 67 SHEET AS | 1 | |
| 4661030 | 68 COVER AS-SOUND SUPPRESSION | 1 | |
| 3374676 | INSULATION | 3 | |
| 5118273 | 69 SHEET AS-SOUND SUPPRESSION | 1 | |
| 0950841 | 70 PIN-COTTER | 2 | |
| 1358572 | 71 BOLT AS | 18 | |
| 1358573 | 72 BOLT AS | 73 | |
| 1358575 | 73 BOLT AS | 85 | |
| 1358577 | 74 BOLT AS | 6 | |
| 5P0372 | 75 LOCK PIN | 2 | |
| 7X2550 | 76 BOLT (M12X1.75X110-MM) | 2 | |
| 7Y2854 | 77 SPACER (24X38X3-MM THK) | 3 | |
| 8T4121 | 78 WASHER-HARD (11X21X2.5-MM THK) | 22 | |
| 8T4133 | 79 NUT (M10X1.5-THD) | 5 | |
| 8T4136 | 80 BOLT (M10X1.5X25-MM) | 4 | |
| 8T4137 | 81 BOLT (M10X1.5X20-MM) | 18 | |
| 8T4183 | 82 BOLT (M12X1.75X40-MM) | 4 | |
| 8T4184 | 83 BOLT (M12X1.75X45-MM) | 3 | |
| 8T4189 | 84 BOLT (M8X1.25X20-MM) | 6 | |
| 8T4223 | 85 WASHER-HARD (13.5X25.5X3-MM THK) | 7 | |
| 8T4224 | 86 WASHER-HARD (8.8X16X2-MM THK) | 14 | |
| 1785678 | 87 BOSS | 4 |
