System And Components
466-1121 FRAME GP-UNDERCARRIAGE -WIDES/N RBF1-UP
Group No: 466-1121 · Commonality
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 4I5006 | 1 SPACER (37X70X45-MM THK) | 20 | |
| 1048147 | 2 PLUG | 16 | |
| 1327299 | 3 SPACER (31X70X51.5-MM THK) | 4 | |
| 2464287 | 4 FRAME AS-CARBODY | 1 | |
| 3480617 | 5 STEP | 4 | |
| 4471719 | 6 BOLT (M20X2.5X60-MM) | 24 | |
| 4512176 | 7 WASHER-HARD (22X35X3.5-MM THK) | 24 | |
| 4532858 | 8 BOLT (M30X3.5X80-MM) | 4 | |
| 4661122 | 9 FRAME AS-TRACK ROLLER (RH SIDE) | 1 | |
| 4661123 | 10 FRAME AS-TRACK ROLLER (LH SIDE) | 1 | |
| 1461799 | 11 WASHER-HARD (39X66X6-MM THK) | 18 | |
| 1470169 | 12 BOLT (M36X4X150-MM) | 38 |
