System And Components
341-2814 CYLINDER & SEAL GP-BUCKETS/N RBF1-UP
Group No: 341-2814 · Commonality
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 3521100 | 1 CYLINDER AS-HYDRAULIC | 1 | |
| 3575712 | 1A BUSHING | 1 | |
| 3521106 | 2 ROD AS-HYDRAULIC CYLINDER | 1 | |
| 2417382 | 2A BUSHING | 1 | |
| 1772611 | 3 HEAD | 1 | |
| 0951717 | 4 SEAL-O-RING | 1 | |
| 0963964 | 5 RING-BACKUP | 1 | |
| 0964402 | 6 BUSHING | 1 | |
| 0940747 | 7 RING-RETAINING | 1 | |
| 3500952 | 8 SEAL-BUFFER | 1 | |
| 3500957 | 9 SEAL-U-CUP | 1 | |
| 0961568 | 10 RING-BACKUP | 1 | |
| 4560192 | 11 SEAL-LIP TYPE | 1 | |
| 2478885 | 12 PISTON | 1 | |
| 0860255 | 13 RING | 2 | |
| 2478865 | 14 RING | 2 | |
| 0967803 | 15 SEAL AS | 1 | |
| 4I3615 | 16 RING-BACKUP | 2 | |
| 0963216 | 17 SETSCREW-SOCKET (M12X1.75X12-MM) | 1 | |
| 3D2891 | 18 BALL | 1 | |
| 8T1447 | 19 BOLT-SOCKET HEAD (M16X2X70-MM) | 12 | |
| 1661494 | 20 SEAL-LIP TYPE | 2 | |
| 2357679 | 21 SEAL-LIP TYPE | 2 | |
| 3B8489 | 22 FITTING-GREASE (1/8-27 PTF) | 2 | |
| 4560207 | KIT-SEAL (BUCKET CYLINDER)(BUCKET CYLINDER) | 1 |
