System And Components
419-5749 CYLINDER GP-BOOMS/N RBF1-UP
Group No: 419-5749 · Commonality
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 7Y4956 | 1 LOCKNUT (M90X2-THD) | 1 | |
| 1915648 | 2 SEAL-LIP TYPE | 1 | |
| 2316843 | 3 RING-SEAL | 1 | |
| 3249486 | 4 SEAL-U-CUP | 1 | |
| 3588440 | 5 CYLINDER AS | 1 | |
| 3324991 | 5A BUSHING | 1 | |
| 3588450 | 6 ROD AS | 1 | |
| 2285621 | 6A BUSHING | 1 | |
| 3588525 | 7 PISTON | 1 | |
| 3597188 | 8 STOP | 1 | |
| 3751723 | 9 HEAD | 1 | |
| 3751732 | 10 RING-BACKUP | 2 | |
| 1400240 | 11 SEAL-O-RING | 1 | |
| 1915604 | 12 RING | 2 | |
| 1915605 | 13 RING | 1 | |
| 1915643 | 14 RING-RETAINING | 1 | |
| 1915644 | 15 BUSHING | 1 | |
| 1915647 | 16 RING-BACKUP | 1 | |
| 3249484 | 17 SEAL-BUFFER | 1 | |
| 7Y5239 | 18 BOLT-SOCKET HEAD (M24X3X100-MM) | 8 | |
| 5062322 | 19 SEAL AS | 1 | |
| 5185137 | KIT-SEAL (BOOM CYLINDER) | 1 |
