System And Components
473-6147 LINES GP-AUXILIARY HYDRAULIC -HIGH PRESSURES/N RBF1-UP
Group No: 473-6147 · Commonality
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 3892407 | 1 VALVE GP-MANUAL (AUXILIARY, SHUTOFF, 2-WAY FLOW) | 1 | |
| 4420234 | 2 VALVE AS-BALL (AUXILIARY, SHUTOFF) | 1 | |
| 3J1907 | SEAL-O-RING | 2 | |
| 9S8004 | PLUG (9/16-18-THD) | 2 | |
| 3029466 | HANDLE | 1 | |
| 4471707 | 3 BOLT (M16X2X60-MM) | 8 | |
| 4512175 | 4 WASHER-HARD (17.5X30X3.5-MM THK) | 10 | |
| 4532836 | 5 BOLT (M16X2X45-MM) | 4 | |
| 4532840 | 6 BOLT (M16X2X140-MM) | 2 | |
| 4736174 | 7 HOSE AS | 1 | |
| 4736177 | 8 HOSE AS | 1 | |
| 4736232 | 9 TUBE AS | 2 | |
| 4736235 | 10 TUBE AS | 1 | |
| 4736236 | 11 TUBE AS | 1 | |
| 1737916 | 12 CLAMP-HALF | 20 | |
| 1P3704 | 13 SEAL-RECTANGULAR | 5 | |
| 1P3705 | 14 SEAL-RECTANGULAR | 4 | |
| 1P3706 | 15 SEAL-RECTANGULAR | 1 | |
| 1P5767 | 16 FLANGE-HALF | 8 | |
| 5P0048 | 17 COVER | 1 | |
| 5P0049 | 18 COVER | 1 | |
| 5P8077 | 19 FLANGE-HALF | 4 | |
| 7X0584 | 20 WASHER-HARD (13.5X20.5X2-MM THK) | 12 | |
| 8C8992 | 21 BOLT-LOCKING (M12X1.75X30-MM) | 20 | |
| 8T4121 | 22 WASHER-HARD (11X21X2.5-MM THK) | 2 | |
| 8T4183 | 23 BOLT (M12X1.75X40-MM) | 4 | |
| 8T4184 | 24 BOLT (M12X1.75X45-MM) | 12 | |
| 8T4194 | 25 BOLT (M12X1.75X50-MM) | 12 | |
| 8T4223 | 26 WASHER-HARD (13.5X25.5X3-MM THK) | 36 | |
| 8T6685 | 27 BOLT (M10X1.5X110-MM) | 2 |
