Assembly
100%

473-6241 LINES GP-AUXILIARY HYDRAULIC -MEDIUM PRESSURES/N RBF1-UP

Group No: 473-6241 · Commonality
Part NumberPart NameQty
6C67601 MANIFOLD2
11586452 GUARD2
18799813 SUPPORT AS5
19723844 SUPPORT AS5
20270025 PLATE1
35989116 PLATE1
45121757 WASHER-HARD (17.5X30X3.5-MM THK)2
45328348 BOLT (M16X2X30-MM)2
45328409 BOLT (M16X2X140-MM)2
473624210 HOSE AS2
473625211 TUBE AS2
473625612 TUBE AS1
473625713 TUBE AS1
202700114 CLIP20
204228115 STRAP-CABLE6
250144016 ADAPTER AS2
3K0360SEAL-O-RING1
7X3164ADAPTER-SWIVEL1
3E800417 BOLT (M12X1.75X45-MM)20
6V839818 SEAL-O-RING4
7J910819 SEAL-O-RING2
7X254320 BOLT (M10X1.5X120-MM)2
8T412121 WASHER-HARD (11X21X2.5-MM THK)6
8T413622 BOLT (M10X1.5X25-MM)2
8T413923 BOLT (M12X1.75X30-MM)20
8T422324 WASHER-HARD (13.5X25.5X3-MM THK)20
8T646625 BOLT (M10X1.5X60-MM)4
8T797126 WASHER-HARD (13.5X25.5X5-MM THK)20
8T413927 BOLT (M12X1.75X30-MM)20
8T422328 WASHER-HARD (13.5X25.5X3-MM THK)20
