System And Components
474-0165 LINES GP-AUXILIARY HYDRAULIC -HIGH PRESSURES/N RBF1-UP
Group No: 474-0165 · Commonality
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 4I8784 | 1 FLANGE | 1 | |
| 1211948 | 2 PLATE | 2 | |
| 2479303 | 3 PLATE | 12 | |
| 2479305 | 4 PLATE | 4 | |
| 3372543 | 5 PLATE | 2 | |
| 3568022 | 6 HOSE AS | 1 | |
| 3568077 | 7 HOSE AS | 1 | |
| 4471703 | 8 BOLT (M16X2X120-MM) | 4 | |
| 4471704 | 9 BOLT (M16X2X90-MM) | 4 | |
| 4471707 | 10 BOLT (M16X2X60-MM) | 40 | |
| 4471711 | 11 BOLT (M16X2X50-MM) | 32 | |
| 4512175 | 12 WASHER-HARD (17.5X30X3.5-MM THK) | 84 | |
| 4532837 | 13 BOLT (M16X2X55-MM) | 4 | |
| 4740231 | 14 TUBE AS | 1 | |
| 4740232 | 15 TUBE AS | 1 | |
| 4740233 | 16 TUBE AS | 1 | |
| 4740234 | 17 TUBE AS | 1 | |
| 1240909 | 18 CLIP | 18 | |
| 1287514 | 19 CLIP | 18 | |
| 1P3704 | 20 SEAL-RECTANGULAR | 2 | |
| 1P3705 | 21 SEAL-RECTANGULAR | 4 | |
| 1P3706 | 22 SEAL-RECTANGULAR | 1 | |
| 1P5767 | 23 FLANGE-HALF | 4 | |
| 5P8077 | 24 FLANGE-HALF | 4 | |
| 7X0584 | 25 WASHER-HARD (13.5X20.5X2-MM THK) | 4 | |
| 7X2550 | 26 BOLT (M12X1.75X110-MM) | 4 | |
| 8T4184 | 27 BOLT (M12X1.75X45-MM) | 4 | |
| 8T4194 | 28 BOLT (M12X1.75X50-MM) | 4 | |
| 8T4223 | 29 WASHER-HARD (13.5X25.5X3-MM THK) | 8 |
