System And Components
474-0242 LINES GP-AUXILIARY HYDRAULIC -MEDIUM PRESSURES/N RBF1-UP
Group No: 474-0242 · Commonality
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 4512183 | 1 NUT (M16X2-THD) | 4 | |
| 1795260 | 2 CLIP | 8 | |
| 1879833 | 3 PLATE | 4 | |
| 1936662 | 4 PLATE | 4 | |
| 2373016 | 5 SUPPORT AS | 1 | |
| 2479440 | 6 SUPPORT AS | 2 | |
| 2946317 | 7 CLAMP AS-LINE | 8 | |
| 4471704 | 8 BOLT (M16X2X90-MM) | 8 | |
| 4471707 | 9 BOLT (M16X2X60-MM) | 4 | |
| 4512175 | 10 WASHER-HARD (17.5X30X3.5-MM THK) | 12 | |
| 4740243 | 12 TUBE AS | 2 | |
| 4740244 | 13 TUBE AS | 1 | |
| 4740245 | 14 TUBE AS | 1 | |
| 2027001 | 15 CLIP | 4 | |
| 2027021 | 16 CLIP | 10 | |
| 6V8398 | 17 SEAL-O-RING | 4 | |
| 7J9108 | 18 SEAL-O-RING | 2 | |
| 8T4139 | 19 BOLT (M12X1.75X30-MM) | 16 | |
| 8T4183 | 20 BOLT (M12X1.75X40-MM) | 2 | |
| 8T4223 | 21 WASHER-HARD (13.5X25.5X3-MM THK) | 30 | |
| 8T4648 | 22 BOLT (M12X1.75X70-MM) | 8 | |
| 8T4956 | 23 BOLT (M12X1.75X35-MM) | 4 |
