System And Components
474-1461 LINES GP-BOOM -LONG REACH, STICK LOAD CONTROLS/N RBF1-UP
Group No: 474-1461 · Commonality
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 4I9523 | 1 BAND-MARKER (BLUE, L3) | 2 | |
| 7K1181 | 2 STRAP-CABLE | 34 | |
| 1335813 | 3 BAND-MARKER (GRAY, P) | 2 | |
| 1579338 | 4 PLATE | 1 | |
| 2166533 | 5 PLATE | 1 | |
| 2337881 | 6 VALVE-CHECK (BOOM LOWERING CONTROL) | 1 | |
| 2827106 | 7 GROMMET | 5 | |
| 4512175 | 8 WASHER-HARD (17.5X30X3.5-MM THK) | 8 | |
| 4512180 | 9 BOLT (M16X2X35-MM) | 6 | |
| 4531256 | 10 BOLT (M16X2X110-MM) | 2 | |
| 4684633 | 11 CLIP AS | 2 | |
| 4684639 | 12 CLIP AS | 3 | |
| 4741462 | 13 TUBE AS | 1 | |
| 4741467 | 14 TUBE AS | 1 | |
| 4741473 | 15 HOSE AS | 1 | |
| 5045156 | 16 SUPPORT AS | 1 | |
| 5045160 | 17 HOSE AS | 1 | |
| 5045161 | 18 HOSE AS | 1 | |
| 1488326 | 19 CONNECTOR AS | 1 | |
| 3J7354 | SEAL-O-RING | 1 | |
| 6V8397 | SEAL-O-RING | 1 | |
| 6V9872 | CONNECTOR | 1 | |
| 1488336 | 20 CONNECTOR AS | 1 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 6V8397 | SEAL-O-RING | 1 | |
| 6V8636 | CONNECTOR | 1 | |
| 1495452 | 21 UNION AS (STRAIGHT) | 1 | |
| 6V8397 | SEAL-O-RING | 2 | |
| 6V8994 | UNION (STRAIGHT) | 1 | |
| 2166515 | 22 CLIP | 3 | |
| 2536444 | 23 CLIP | 2 | |
| 5Q4212 | 24 CLIP | 2 | |
| 6V8398 | 25 SEAL-O-RING | 3 | |
| 6V9168 | 26 NUT (11/16-16-THD) | 1 | |
| 7X2534 | 27 BOLT (M6X1X50-MM) | 2 | |
| 7X2549 | 28 BOLT (M12X1.75X100-MM) | 2 | |
| 8T4139 | 29 BOLT (M12X1.75X30-MM) | 4 | |
| 8T4223 | 30 WASHER-HARD (13.5X25.5X3-MM THK) | 6 | |
| 9X8256 | 31 WASHER (6.6X12X2-MM THK) | 2 | |
| 4471703 | 32 BOLT (M16X2X120-MM) | 2 |
