System And Components
330-2499 LINES GP-CONTROL -REARS/N RBF1-UP
Group No: 330-2499 · Commonality
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 7X2456 | 1 BOLT (M12X1.75X190-MM) | 4 | |
| 8C0620 | 2 PROTECTOR-THREAD | 2 | |
| 1708553 | 3 BOLT-SOCKET HEAD (M12X1.75X40-MM) | 4 | |
| 2094582 | 4 CLAMP-T BOLT | 2 | |
| 3237671 | 5 VALVE GP-CHECK (RETURN) | 1 | |
| 6V2483 | SEAL-O-RING | 1 | |
| 0951575 | SEAL-O-RING | 1 | |
| 0951708 | SEAL-O-RING | 1 | |
| 3337092 | 6 SUPPORT AS | 1 | |
| 3337094 | 7 SUPPORT | 1 | |
| 3372663 | 8 PIPE AS | 1 | |
| 3515031 | 9 HOSE | 1 | |
| 3598473 | 10 HOSE AS | 1 | |
| 3598474 | 11 HOSE AS | 1 | |
| 0964884 | 12 LOCKNUT (M12X1.75-THD) | 2 | |
| 1322155 | 13 U-BOLT | 1 | |
| 1488354 | 14 ELBOW AS | 1 | |
| 3K0360 | SEAL-O-RING | 1 | |
| 6V8398 | SEAL-O-RING | 1 | |
| 6V9002 | ELBOW | 1 | |
| 1488407 | 15 PLUG AS | 1 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 9S4191 | PLUG (9/16-18-THD) | 1 | |
| 1488408 | 16 PLUG AS | 1 | |
| 3D2824 | SEAL-O-RING | 1 | |
| 9S4183 | PLUG (1-1/16-12-THD) | 1 | |
| 1P3704 | 17 SEAL-RECTANGULAR | 4 | |
| 1P4578 | 18 FLANGE-HALF | 2 | |
| 1P5767 | 19 FLANGE-HALF | 4 | |
| 4J0522 | 20 SEAL-O-RING | 1 | |
| 4J0527 | 21 SEAL-O-RING | 1 | |
| 5H4020 | 22 COVER | 1 | |
| 6J2680 | 23 SEAL-O-RING | 1 | |
| 6V1572 | 24 CLIP (SLOT) | 2 | |
| 6V1573 | 25 CLIP (TAB) | 2 | |
| 6V1875 | 26 GROMMET | 2 | |
| 8T4121 | 27 WASHER-HARD (11X21X2.5-MM THK) | 6 | |
| 8T4139 | 28 BOLT (M12X1.75X30-MM) | 4 | |
| 8T4186 | 29 BOLT (M10X1.5X40-MM) | 2 | |
| 8T4194 | 30 BOLT (M12X1.75X50-MM) | 8 | |
| 8T4223 | 31 WASHER-HARD (13.5X25.5X3-MM THK) | 18 | |
| 8T4182 | 32 BOLT (M10X1.5X45-MM) | 2 |
