System And Components
424-9525 LINES GP-PUMPS/N RBF1-UP
Group No: 424-9525 · Commonality
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 2724379 | 1 HOSE | 1 | |
| 3334554 | 2 PIPE AS | 1 | |
| 3334557 | 3 PIPE AS | 1 | |
| 3507217 | 4 HOSE AS | 2 | |
| 3681714 | 5 SUPPORT AS | 1 | |
| 1132003 | 6 BOLT-SOCKET HEAD (M16X2X40-MM) | 4 | |
| 1488391 | 7 ELBOW AS | 2 | |
| 2S4078 | SEAL-O-RING | 1 | |
| 5K9090 | SEAL-O-RING | 1 | |
| 8T8987 | ELBOW | 1 | |
| 1488407 | 8 PLUG AS | 1 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 9S4191 | PLUG (9/16-18-THD) | 1 | |
| 1488411 | 9 PLUG AS | 2 | |
| 3K0360 | SEAL-O-RING | 1 | |
| 9S4185 | PLUG (3/4-16-THD) | 1 | |
| 1P3703 | 10 SEAL-RECTANGULAR | 2 | |
| 1P4578 | 11 FLANGE-HALF | 2 | |
| 1P5767 | 12 FLANGE-HALF | 4 | |
| 4J0522 | 13 SEAL-O-RING | 1 | |
| 5H4020 | 14 COVER | 1 | |
| 5H8624 | 15 SEAL-O-RING | 1 | |
| 6V0400 | 16 FLANGE-HALF | 4 | |
| 8T4121 | 17 WASHER-HARD (11X21X2.5-MM THK) | 4 | |
| 8T4194 | 18 BOLT (M12X1.75X50-MM) | 16 | |
| 8T4196 | 19 BOLT (M10X1.5X35-MM) | 4 | |
| 8T4223 | 20 WASHER-HARD (13.5X25.5X3-MM THK) | 16 | |
| 4533446 | 21 BOLT (M12X1.75X35-MM) | 4 | |
| 4471719 | 22 BOLT (M20X2.5X60-MM) | 4 | |
| 9M3786 | 23 SEAL-O-RING | 1 | |
| 9X6654 | 24 CLAMP-HOSE | 4 | |
| 4512175 | 25 WASHER-HARD (17.5X30X3.5-MM THK) | 4 | |
| 4512182 | 26 WASHER-HARD (13.5X25.5X3-MM THK) | 4 |
