System And Components
472-0939 LINES GP-TRAVEL MOTORS/N RBF1-20006
Group No: 472-0939 · Commonality
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 7K1181 | 1 STRAP-CABLE | 10 | |
| 1087118 | 2 GROMMET | 2 | |
| 2661302 | 3 HOSE AS | 2 | |
| 1295947 | 4 GROMMET | 2 | |
| 1346835 | 5 GROMMET | 2 | |
| 1346955 | 6 GROMMET | 2 | |
| 1655085 | 7 BOLT-SOCKET HEAD (M12X1.75X160-MM) | 12 | |
| 4720943 | 8 HOSE AS | 2 | |
| 2667843 | 9 VALVE GP-TRAVEL COUNTERBALANCE (TRACTION CONTROL) | 2 | |
| 2786469 | 10 GROMMET | 2 | |
| 4720941 | 11 HOSE AS | 4 | |
| 1488338 | 12 CONNECTOR AS | 2 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 6V8397 | SEAL-O-RING | 1 | |
| 8T0075 | CONNECTOR | 1 | |
| 1488347 | 13 ELBOW AS | 2 | |
| 3D2824 | SEAL-O-RING | 1 | |
| 6V9007 | ELBOW | 1 | |
| 6V9746 | SEAL-O-RING | 1 | |
| 1488378 | 14 ELBOW AS | 2 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 6V8397 | SEAL-O-RING | 1 | |
| 6V8724 | ELBOW | 1 | |
| 1645574 | 15 TEE AS | 1 | |
| 3D2824 | SEAL-O-RING | 1 | |
| 6V8784 | TEE-FACE SEAL | 1 | |
| 6V9746 | SEAL-O-RING | 2 | |
| 1P3703 | 16 SEAL-RECTANGULAR | 4 | |
| 1P3704 | 17 SEAL-RECTANGULAR | 4 | |
| 1P5767 | 18 FLANGE-HALF | 8 | |
| 6V0400 | 19 FLANGE-HALF | 16 | |
| 7G5984 | 20 CLIP (TAB) | 2 | |
| 7G5985 | 21 CLIP (SLOT) | 2 | |
| 8T4184 | 22 BOLT (M12X1.75X45-MM) | 48 | |
| 8T4192 | 23 BOLT (M12X1.75X25-MM) | 4 | |
| 8T4223 | 24 WASHER-HARD (13.5X25.5X3-MM THK) | 52 |
