390-1088 MOTOR GP-TRAVELS/N RBF1-20006

Group No: 390-1088 · Commonality

Part Number	Part Name	Qty
1T0936	1 PLUG-ORIFICE	2
4B4158	2 SCREW-DRIVE (NO 4X0.25-IN)	4
6V3382	3 SEAL-LIP TYPE	1
8J2559	4 PLATE-WARNING (OIL FILL)	1
0874786	5 ADAPTER	1
1185805	6 BEARING-SPECIAL RACE	1
1241530	7 BARREL AS	1
1241536	8 DISC-FRICTION	5
1241537	9 PLATE-SEPARATOR	6
1241554	10 SPRING	1
1241557	11 RETAINER	2
1241561	12 SPRING-BRAKE	20
1264002	13 SEAL-O-RING	2
1264003	14 SEAL-O-RING	1
1264004	15 RING-BACKUP	1
1264040	16 RING-BACKUP	1
1375646	17 SPACER (70.4X87.5X7.6-MM THK)	1
1437140	18 KEY	2
1483548	19 BEARING-SPECIAL RACE	1
1491207	20 PLATE	1
1554897	21 PISTON AS	9
1597320	22 PLATE-RETAINER	1
1673872	23 SPOOL	1
1757887	24 DOWEL	2
1846014	25 BODY AS	1
1241555	PLUG	4
1846015	26 HEAD GP-PUMP	1
0965916	SEAT	2
1241555	PLUG	8
1932301	27 SHAFT	1
1954456	28 PLUG-ORIFICE	1
2266544	29 PISTON-BRAKE	1
2305483	30 SPRING	1
2316550	31 HOLD-DOWN	1
2323868	32 WASHER-BELLEVILLE	4
3565227	33 PISTON-ACTUATOR	1
3571728	34 SPACER (70.4X80X2.3-MM THK)	1
3901087	35 PLATE-CAM	1
0965919	36 RING-BACKUP	2
0951572	37 SEAL-O-RING	2
1241541	38 PIN	2
1437319	39 RACE-ROLLER BEARING	1
2D6642	40 BALL	2
2M9780	41 SEAL-O-RING	1
2R1236	42 RING-RETAINING (LOCK, INTERNAL)	1
3D2824	43 SEAL-O-RING	2
3K0360	44 SEAL-O-RING	2
5B9318	45 BALL	1
5P7684	46 PLUG	1
6K6307	47 SEAL-O-RING	1
7Y5219	48 SEAL-O-RING	2
2135007	49 BOLT (M20X2.5X80-MM)	6
9S4183	50 PLUG (1-1/16-12-THD)	2
9S4185	51 PLUG (3/4-16-THD)	2
2266473	KIT-SEAL (TRAVEL MOTOR)	1
