System And Components
497-8498 PUMP GP-MAIN HYDRAULICS/N RBF1-UP
Group No: 497-8498 · Commonality
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 2959497 | 1 HEAD GP-PUMP | 2 | |
| 3421907 | 2 SHAFT-DRIVE | 1 | |
| 2959499 | 3 SHAFT-DRIVEN | 1 | |
| 2478713 | 4 BEARING-ROLLER | 1 | |
| 2959500 | 5 BEARING-ROLLER | 1 | |
| 2959693 | 6 BEARING-NEEDLE | 1 | |
| 2478715 | 7 BEARING-NEEDLE | 1 | |
| 2478944 | 8 BUSHING | 1 | |
| 2478717 | 9 SPACER (65X90X1-MM THK) | 2 | |
| 2959501 | 10 SPACER (49.5X73X3-MM THK) | 1 | |
| 2478719 | 11 SPACER (50X64X3-MM THK) | 1 | |
| 2478720 | 12 SPACER (95X110X3.2-MM THK) | 1 | |
| 2959502 | 13 SPACER (55X69X3-MM THK) | 2 | |
| 2959503 | 14 SPACER (104X120X3.2-MM THK) | 1 | |
| 2478721 | 15 IMPELLER | 1 | |
| 2959504 | 16 PLATE | 2 | |
| 2959505 | 17 RETAINER-BALL | 2 | |
| 2959506 | 18 SPRING | 18 | |
| 2959507 | 19 FLANGE | 1 | |
| 2959508 | 20 GEAR-DRIVE | 1 | |
| 2959509 | 21 GEAR-DRIVEN | 1 | |
| 2959510 | 22 PLATE | 2 | |
| 2478725 | 23 PLATE | 1 | |
| 2959511 | 24 PLATE | 1 | |
| 2478726 | 25 COVER | 1 | |
| 2590813 | 26 COVER | 1 | |
| 2959512 | 27 COVER | 1 | |
| 4978506 | 28 BODY AS | 1 | |
| 3717201 | PLUG (M7X0.75-THD) | 7 | |
| 4978507 | 29 BLOCK | 1 | |
| 2529167 | 30 BOLT-SOCKET HEAD (M8X1.25X30-MM) | 8 | |
| 6V8200 | 31 BOLT-SOCKET HEAD (M12X1.75X35-MM) | 10 | |
| 8T0343 | 32 BOLT-SOCKET HEAD (M12X1.75X55-MM) | 11 | |
| 2491306 | 33 BOLT-SOCKET HEAD (M22X2.5X60-MM) | 9 | |
| 2491307 | 34 BOLT-SOCKET HEAD (M22X2.5X95-MM) | 2 | |
| 2491308 | 35 BOLT-SOCKET HEAD (M22X2.5X180-MM) | 1 | |
| 8T9080 | 36 BOLT-SOCKET HEAD (M12X1.75X20-MM) | 8 | |
| 1105525 | 37 PLUG | 4 | |
| 2069290 | 38 SEAL-O-RING | 8 | |
| 1963784 | 39 PLUG | 8 | |
| 7I8164 | 40 ORIFICE (1/16-NPTF) | 4 | |
| 1709997 | 41 PLUG | 2 | |
| 2426914 | 42 PISTON-SERVO | 2 | |
| 7I8166 | 43 STOPPER | 2 | |
| 2426915 | 44 STOPPER | 2 | |
| 2478729 | 45 COVER | 2 | |
| 1091296 | 46 SEAL-O-RING | 2 | |
| 2366919 | 47 SEAL-O-RING | 1 | |
| 2496657 | 48 SEAL-O-RING | 1 | |
| 3476530 | 49 SEAL-RECTANGULAR | 9 | |
| 2069291 | 50 SEAL-O-RING | 2 | |
| 2147568 | 51 SEAL-O-RING | 4 | |
| 1091294 | 52 SEAL-O-RING | 2 | |
| 2496670 | 53 SEAL-O-RING | 1 | |
| 3264415 | 54 GASKET | 2 | |
| 2959695 | 55 SEAL-LIP TYPE | 1 | |
| 7I8171 | 56 RING-BACKUP | 2 | |
| 7I8172 | 57 RING-BACKUP | 2 | |
| 4512184 | 58 NUT (M20X2.5-THD) | 2 | |
| 2426918 | 59 NUT (M20X2.5-THD) | 2 | |
| 8T4241 | 60 RING-RETAINING | 2 | |
| 0950929 | 61 RING-RETAINING | 2 | |
| 0965516 | 62 RING-RETAINING (EXTERNAL) | 2 | |
| 0950944 | 63 RING-RETAINING | 1 | |
| 2478787 | 64 RING-RETAINING | 1 | |
| 2959516 | 65 RING | 1 | |
| 2478730 | 66 RING-RETAINING | 1 | |
| 2344539 | 67 DOWEL | 2 | |
| 0950882 | 68 PIN-SPRING | 4 | |
| 2959517 | 69 DOWEL | 1 | |
| 2478786 | 70 DOWEL | 2 | |
| 2478985 | 71 DOWEL | 4 | |
| 2426919 | 72 SETSCREW (M20X2.5X56-MM) | 2 | |
| 2003292 | 73 SETSCREW (M20X2.5X90-MM) | 2 | |
| 3739477 | 74 WASHER | 11 | |
| 4884578 | 75 PIN AS | 2 | |
| 3421906 | 76 PUMP GP-GEAR (PILOT) | 1 | |
| 4651024 | 77 PISTON AS | 2 | |
| 3119505 | 78 BARREL AS-PUMP | 1 | |
| 3119506 | 79 BARREL AS-PUMP | 1 | |
| 2959521 | 80 SWASHPLATE AS | 2 | |
| 4978514 | 81 VALVE GP-SOLENOID (PUMP CONTROL) | 1 | |
| 2069292 | 82 SEAL-O-RING | 2 |
