316-8831 GUARD GP-FRONT WINDOWS/N RBF1-UP

Group No: 316-8831 · Commonality

Part Number	Part Name	Qty
5D4822	1 RING-RETAINING	4
4E1487	2 KNOB	2
8Y5745	3 LATCH AS	2
5609515	4 STOPPER	2
1725291	5 SCREW (M10X1.5X30-MM)	8
1863782	6 BOSS	2
2014534	7 BOLT (M16X2X26-MM)	2
2034457	8 GROMMET	2
2190305	9 FILM-WARNING (NO WELD, NO DRILL, READ OMM)	1
4862779	10 FILM-WARNING (FRONT GUARD, NO WELD, READ OMM)	1
3361159	11 SUPPORT AS	1
3361160	12 SUPPORT AS	1
3361161	13 GUARD AS	1
8T4133	NUT (M10X1.5-THD)	1
9R2672	BOSS-THREADED (M10X1.5X20-MM)	1
4512183	NUT (M16X2-THD)	1
3361163	14 BRACKET AS	2
3423717	16 BRACKET AS	2
3423723	17 SPRING AS-GAS (FRONT WINDOW GUARD)	2
3467367	18 PEDAL AS	1
3467370	19 PEDAL AS	1
4160862	20 CUSHION	2
3573956	21 STRIKER AS	2
8T3612	NUT-WELD (M8X1.25-THD)	3
0966331	22 NUT (M12X1.75-THD)	4
6V7357	23 BOLT (M6X1X25-MM)	8
7Y0623	24 LOCKNUT (M16X2-THD)	2
8T4121	25 WASHER-HARD (11X21X2.5-MM THK)	10
8T4136	26 BOLT (M10X1.5X25-MM)	2
8T4223	27 WASHER-HARD (13.5X25.5X3-MM THK)	4
5P4116	28 WASHER-HARD (8.8X20.5X2-MM THK)	6
8T4908	29 BOLT (M8X1.25X25-MM)	6
9X6165	30 WASHER (6.5X22X2.5-MM THK)	2
9X8256	31 WASHER (6.6X12X2-MM THK)	6
0997241	32 WASHER-HARD (19X34X3-MM THK)	2
