System And Components
336-6293 HORN GP-ELECTRICS/N RBF1-UP
Group No: 336-6293 · Commonality
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 7K1181 | 1 STRAP-CABLE | 1 | |
| 7Y3919 | 2 HORN AS (24-VOLT, LOW TONE) | 1 | |
| 7Y3920 | 3 HORN AS (24-VOLT, HIGH TONE) | 1 | |
| 1H4393 | LOCKWASHER | 2 | |
| 0957930 | SCREW-MACHINE (M4X0.7X6-MM) | 2 | |
| 3366294 | 4 HARNESS AS-ALARM | 1 | |
| 9W0852 | PIN-CONNECTOR (14-GA TO 16-GA) | 2 | |
| 2L8065 | TERMINAL-RING (10-GA TO 12-GA, NO. 8 SCREW) | 2 | |
| 2L8075 | TERMINAL-RING (14-GA TO 16-GA, NO. 8 SCREW) | 2 | |
| 2434505 | RECEPTACLE AS-CONNECTOR (2-PIN) | 1 | |
| 4635630 | 5 BRACKET AS | 1 | |
| 1325789 | 6 CLIP (LADDER) | 1 | |
| 8T4224 | 7 WASHER-HARD (8.8X16X2-MM THK) | 3 | |
| 8T4200 | 8 BOLT (M8X1.25X16-MM) | 3 |
