383-5591 LINES GP-AIR CONDITIONERS/N RBF1-UP

Group No: 383-5591 · Commonality
Part NumberPart NameQty
7Y45291 GROMMET1
7Y81682 GROMMET1
08765983 GROMMET1
13121714 CONNECTOR1
22557995 HOSE-DRAIN2
22558006 CLAMP2
30504417 BAND-MARKER (HS)2
30504428 BAND-MARKER (HR)2
32671959 BRACKET AS1
327655810 DRYER-REFRIGERANT (RECEIVER)1
336120911 BRACKET AS1
383565612 HOSE AS-REFRIGERANT1
1133467SEAL-O-RING1
2457850CAP1
383565713 HOSE AS-REFRIGERANT1
1133468SEAL-O-RING1
2457851CAP1
383565814 HOSE AS-REFRIGERANT1
1217063SEAL-O-RING2
383565915 PIPE AS1
1217063SEAL-O-RING2
100433616 CLIP (LOOP)1
235901417 CLAMP-SPRING4
2M978018 SEAL-O-RING1
336648219 CLIP (LOOP)5
336648320 CLIP2
3D282421 SEAL-O-RING1
5C955322 BOLT (M6X1X16-MM)2
5I397823 CLIP4
5P104524 CONNECTOR1
5P432525 CLIP (LOOP)1
6D164126 CLIP (LOOP)7
6V735727 BOLT (M6X1X25-MM)4
7K118128 STRAP-CABLE2
8M277329 CLIP (LOOP)2
8T412130 WASHER-HARD (11X21X2.5-MM THK)16
8T413731 BOLT (M10X1.5X20-MM)16
8T420032 BOLT (M8X1.25X16-MM)2
8T422433 WASHER-HARD (8.8X16X2-MM THK)5
8T490834 BOLT (M8X1.25X25-MM)2
8T497135 BOLT (M6X1X30-MM)1
8T754736 BOLT (M8X1.25X30-MM)1
9X825637 WASHER (6.6X12X2-MM THK)7
5P076738 HOSE (325-CM)
5P076738A HOSE (307.5-CM)
3E829940 SEAL (13.5-CM)
