System And Components
476-2014 LINES GP-FUELS/N SFZ1-UP
Group No: 476-2014
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 3S2093 | 1 STRAP-CABLE | 1 | |
| 4I0379 | 2 VALVE-MANUAL | 1 | |
| 7Y8167 | 3 GROMMET (50-MM ID) | 5 | |
| 1160118 | 4 CLIP | 1 | |
| 2609244 | 5 ELBOW | 1 | |
| 3514105 | 6 PLATE AS | 1 | |
| 3617347 | 7 CONNECTION GP-FUEL | 2 | |
| 3685170 | 8 BRACKET AS | 1 | |
| 3686658 | 9 VALVE | 1 | |
| 5256205 | 10 FILTER-FUEL (IN-LINE) | 1 | |
| 3849223 | 11 TEE AS | 1 | |
| 6V1625 | TEE-O-RING | 1 | |
| 2147568 | SEAL-O-RING | 1 | |
| 4216218 | 12 HOSE AS | 1 | |
| 4216219 | 13 HOSE AS | 1 | |
| 4216220 | 14 HOSE AS | 1 | |
| 4216222 | 15 HOSE AS | 1 | |
| 4465409 | 16 PUMP AS-FUEL TRANSFER (24-VOLT) | 1 | |
| 4830997 | 17 FILTER GP-WATER SEP & FUEL | 1 | |
| 4833870 | 18 BRACKET AS | 1 | |
| 3684691 | LINER | 1 | |
| 1358573 | 19 BOLT AS | 2 | |
| 1984777 | 20 WASHER-HARD (11X25X10-MM THK) | 1 | |
| 2147568 | 21 SEAL-O-RING | 3 | |
| 2385080 | 22 SEAL-O-RING | 1 | |
| 2385081 | 23 SEAL-O-RING | 1 | |
| 2977964 | 24 CONNECTOR | 2 | |
| 3295459 | 25 ADAPTER AS | 1 | |
| 5P1404 | ADAPTER | 1 | |
| 2385081 | SEAL-O-RING | 1 | |
| 3432385 | 26 CLIP (LOOP) | 2 | |
| 3432386 | 27 CLIP (LOOP) | 1 | |
| 3474416 | 28 ADAPTER | 2 | |
| 3514318 | 29 CLIP (LOOP) | 13 | |
| 3514319 | 30 CLIP (LOOP) | 3 | |
| 3514320 | 31 CLIP (LOOP) | 5 | |
| 5P4325 | 32 CLIP (LOOP) | 1 | |
| 5P4924 | 33 ELBOW | 1 | |
| 6K8180 | 34 GROMMET | 2 | |
| 6S8620 | 35 CLAMP-HOSE | 13 | |
| 6V4292 | 36 ELBOW | 1 | |
| 7V6571 | 37 GROMMET | 3 | |
| 7X0818 | 38 BOLT (M8X1.25X45-MM) | 3 | |
| 8T1889 | 39 CLIP (SLOT) | 3 | |
| 8T1890 | 40 CLIP (TAB) | 3 | |
| 8T4121 | 41 WASHER-HARD (11X21X2.5-MM THK) | 31 | |
| 8T4136 | 42 BOLT (M10X1.5X25-MM) | 12 | |
| 8T4137 | 43 BOLT (M10X1.5X20-MM) | 9 | |
| 8T4191 | 44 BOLT (M10X1.5X16-MM) | 2 | |
| 8T4195 | 45 BOLT (M10X1.5X30-MM) | 5 | |
| 8T4196 | 46 BOLT (M10X1.5X35-MM) | 3 | |
| 8T4224 | 47 WASHER-HARD (8.8X16X2-MM THK) | 3 | |
| 9P0719 | 48 GROMMET | 1 | |
| 8C3681 | 49 HOSE-DRAIN (37-CM) | ||
| 3478645 | 50 HOSE (30.2-CM) | ||
| 3478645 | 50A HOSE (31.8-CM) | ||
| 3478645 | 50B HOSE (137-CM) | ||
| 3478646 | 51 HOSE (21.4-CM) | ||
| 3478646 | 51A HOSE (266-CM) | ||
| 3478646 | 51B HOSE (104-CM) |
