System And Components
417-1476 LINES GP-FUEL FILTERS/N D8T1-UP
Group No: 417-1476
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 6I0654 | 1 BOLT (M10X1.5X25-MM) | 2 | |
| 6I0846 | 2 BOLT (M6X1X14-MM) | 1 | |
| 6I4200 | 3 BOLT (M10X1.5X16-MM) | 2 | |
| 1004830 | 4 BOLT (M10X1.5X20-MM) | 3 | |
| 1013917 | 5 WASHER (10.5X21X2-MM THK) | 1 | |
| 1243815 | 6 BOLT (M8X1.25X16-MM) | 4 | |
| 8T4137 | 7 BOLT (M10X1.5X20-MM) | 1 | |
| 1647468 | 8 BOLT (M10X1.5X95-MM) | 2 | |
| 3112732 | 9 TIE-CABLE | 3 | |
| 3523426 | 10 BRACKET AS | 1 | |
| 3577473 | 11 SUPPORT GP-LINES | 1 | |
| 3473429 | 11A CLIP-PIPE | 2 | |
| 3311742 | 12 LINES AS-FUEL | 1 | |
| 3582144 | 13 SUPPORT GP-LINES | 1 | |
| 4623707 | 14 SUPPORT GP-LINES | 1 | |
| 3473429 | 14A CLIP-PIPE | 2 | |
| 3611973 | 15 BRACKET AS | 1 | |
| 3706097 | 16 BRACKET AS | 1 | |
| 3473429 | CLIP-PIPE | 1 | |
| 3169351 | 17 MOUNTING-CABLE TIE | 1 | |
| 3766887 | 18 LINES GP-FUEL | 1 | |
| 2287089 | 18A SEAL-O-RING | 1 | |
| 3985905 | 18B CLIP | 2 | |
| 2774993 | SEAL-O-RING | 1 | |
| 3833462 | 19 LINE AS-FUEL | 1 | |
| 3478645 | 19A HOSE (210-CM) | ||
| 3514318 | 19B CLIP (LOOP) | 1 | |
| 3597115 | CONNECTOR-FUEL | 1 | |
| 3968213 | 20 BRACKET | 1 | |
| 4227164 | 21 CLIP | 1 | |
| 4427872 | 22 BRACKET | 1 | |
| 4459234 | 23 CAP | 1 | |
| 6I0217 | 24 BOLT (M8X1.25X20-MM) | 2 | |
| 6I0254 | 25 BOLT (M8X1.25X30-MM) | 1 |
