System And Components
417-4254 SENSOR GP-ENGINES/N D8T1-UP
Group No: 417-4254
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1243815 | 1 BOLT (M8X1.25X16-MM) | 7 | |
| 1999252 | 2 SEAL-O-RING | 2 | |
| 1999267 | 3 SEAL-O-RING | 4 | |
| 1999751 | 4 SEAL-O-RING | 1 | |
| 2179039 | 5 STRAP-CABLE | 2 | |
| 2566454 | 6 SENSOR-TEMPERATURE (2-PIN) | 2 | |
| 2765603 | 7 SEAL-O-RING | 1 | |
| 3203060 | 8 SENSOR GP-PRESSURE (ENGINE OIL) | 1 | |
| 3203061 | 9 SENSOR GP-PRESSURE | 1 | |
| 3203062 | 10 SENSOR GP-PRESSURE | 1 | |
| 3203063 | 11 SENSOR GP-PRESSURE | 1 | |
| 3327865 | 12 TIE-CABLE | 2 | |
| 3398822 | 13 SENSOR AS-TEMPERATURE | 1 | |
| 2818802 | RECEPTACLE AS-CONNECTOR (2-PIN) | 1 | |
| 3589934 | 14 UNION | 2 | |
| 3691202 | 15 BRACKET AS | 1 | |
| 3850697 | 16 CLAMP | 2 | |
| 3854319 | 17 PIPE AS | 1 | |
| 3308196 | SEAL-O-RING | 2 | |
| 3854320 | 18 PIPE AS | 1 | |
| 3308196 | SEAL-O-RING | 2 | |
| 3887638 | 19 MANIFOLD AS | 1 | |
| 2956661 | PLUG | 1 | |
| 3972874 | 20 SENSOR GP-PRESSURE | 1 | |
| 3410643 | SEAL-RECTANGULAR | 2 | |
| 4162211 | 21 SENSOR GP-TEMPERATURE | 1 | |
| 6I0217 | 22 BOLT (M8X1.25X20-MM) | 2 | |
| 6I0254 | 23 BOLT (M8X1.25X30-MM) | 3 | |
| 2380120 | 24 SENSOR GP-SPEED | 2 | |
| 2284947 | 25 SEAL-O-RING | 2 | |
| 2323861 | 26 PLUG (BLANKING) | 1 | |
| 3308196 | 27 SEAL-O-RING | 1 |
