System And Components
417-4254 SENSOR GP-ENGINES/N D8T1-UP
Group No: 417-4254
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1999267 | 1 SEAL-O-RING | 4 | |
| 2284947 | 2 SEAL-O-RING | 2 | |
| 6I0254 | 3 BOLT (M8X1.25X30-MM) | 3 | |
| 8T7547 | 4 BOLT (M8X1.25X30-MM) | 2 | |
| 1243815 | 5 BOLT (M8X1.25X16-MM) | 7 | |
| 1999252 | 6 SEAL-O-RING | 2 | |
| 1999751 | 7 SEAL-O-RING | 1 | |
| 2061345 | 8 STRAP-CABLE | 1 | |
| 2179039 | 9 STRAP-CABLE | 5 | |
| 2566454 | 10 SENSOR-TEMPERATURE (2-PIN)(INTAKE MANIFOLD) | 1 | |
| 2566454 | 10A SENSOR-TEMPERATURE (2-PIN)(COOLANT) | 1 | |
| 2765603 | 11 SEAL-O-RING | 1 | |
| 3113857 | 12 SENSOR-SPEED (CRANKSHAFT) | 1 | |
| 3113857 | 12A SENSOR-SPEED (CAMSHAFT) | 1 | |
| 3203060 | 13 SENSOR GP-PRESSURE (ENGINE OIL) | 1 | |
| 3203061 | 14 SENSOR GP-PRESSURE (NRS INLET) | 1 | |
| 3203062 | 15 SENSOR GP-PRESSURE (INTAKE MANIFOLD AIR) | 1 | |
| 3203063 | 16 SENSOR GP-PRESSURE (ATMOSPHERIC) | 1 | |
| 3308196 | 17 SEAL-O-RING | 1 | |
| 3327865 | 18 TIE-CABLE | 2 | |
| 4743231 | 19 SENSOR AS-TEMPERATURE (2-PIN)(NRS) | 1 | |
| 2818802 | RECEPTACLE AS-CONNECTOR (2-PIN) | 1 | |
| 3589934 | 20 UNION | 2 | |
| 3691202 | 21 BRACKET AS | 1 | |
| 3176213 | NUT | 1 | |
| 3850697 | 22 CLAMP | 2 | |
| 3851174 | 23 SENSOR GP-PRESSURE (NRS DIFFERENTIAL) | 1 | |
| 3854319 | 24 PIPE AS | 1 | |
| 3308196 | SEAL-O-RING | 2 | |
| 3854320 | 25 PIPE AS | 1 | |
| 3308196 | SEAL-O-RING | 2 | |
| 3887638 | 26 MANIFOLD AS | 1 | |
| 2956661 | PLUG | 1 | |
| 4162211 | 27 SENSOR GP-TEMPERATURE (TURBOCHARGER OUTLET) | 1 | |
| 4223830 | 28 HARNESS AS-SENSOR | 1 | |
| 5310262 | 29 BRACKET AS | 1 | |
| 3176213 | NUT | 1 | |
| 2323861 | 30 PLUG (BLANKING) | 1 |
