System And Components
462-7775 WIRING GP-CABS/N SFZ1-UP
Group No: 462-7775
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 3S2093 | 1 STRAP-CABLE | 8 | |
| 7K1181 | 2 STRAP-CABLE | 9 | |
| 1495050 | 3 RELAY (24-VOLT) | 4 | |
| 2594397 | 4 CLAMP | 1 | |
| 2594399 | 5 BASE | 2 | |
| 3245732 | 6 BRACKET | 2 | |
| 3392675 | 7 SWITCH AS-ROCKER (CAB RISER LIGHT) | 1 | |
| 1673542 | RECEPTACLE-CONNECTOR (5-PIN) | 1 | |
| 1673543 | TERMINAL (MALE) | 4 | |
| 4609122 | 8 DISPLAY GP-MONITOR | 1 | |
| 3995155 | 9 CABLE (ETHERNET) | 1 | |
| 4478283 | 10 CONTROL GP-HANDLE (8-SWITCH, 2-WAY TRIGGER, LH) | 1 | |
| 4478284 | 11 CONTROL GP-HANDLE (8-SWITCH, 2-WAY TRIGGER, RH) | 1 | |
| 4569296 | 12 CONTROLLER | 1 | |
| 4569297 | 13 CONTROLLER | 1 | |
| 4569303 | 14 BRACKET AS | 1 | |
| 4609088 | 15 BRACKET | 1 | |
| 4609157 | 16 PLATE | 2 | |
| 4609158 | 17 PLATE | 2 | |
| 4847856 | 18 HARNESS AS-CAB | 1 | |
| 4657967 | 19 HARNESS AS-WIRING | 1 | |
| 1028805 | KIT-RECEPTACLE (6-PIN) | 1 | |
| 8T8737 | PLUG-SEAL | 3 | |
| 9X3401 | PIN-CONNECTOR (16-GA TO 18-GA) | 2 | |
| 1261767 | PIN-CONNECTOR (14-GA TO 16-GA) | 1 | |
| 9X8256 | 20 WASHER (6.6X12X2-MM THK) | 4 | |
| 1293178 | 21 LOCKNUT (M6X1-THD) | 4 | |
| 1566175 | 22 CLIP (LADDER) | 1 | |
| 5C9553 | 23 BOLT (M6X1X16-MM) | 4 | |
| 9X2042 | 24 SCREW-TRUSS HEAD (M6X1X12-MM) (M6X1X12-MM) | 18 | |
| 9X2043 | 25 SCREW-TRUSS HEAD (M6X1X14-MM) | 3 | |
| 9X2044 | 26 SCREW-TRUSS HEAD (M6X1X16-MM) | 2 |
