System And Components
349-9776 WIRING GP-CAB RISER -TILTINGS/N SFZ1-UP
Group No: 349-9776
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 3S2093 | 1 STRAP-CABLE | 3 | |
| 7K1181 | 2 STRAP-CABLE | 1 | |
| 1114838 | 3 CLIP | 9 | |
| 1114839 | 4 STRAP | 9 | |
| 1160118 | 5 CLIP | 7 | |
| 1496549 | 6 GROMMET | 2 | |
| 1516667 | 7 SUPPORT AS | 1 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 1 | |
| 1673583 | 8 STRAP AS-GROUND | 1 | |
| 2061345 | 9 STRAP-CABLE | 3 | |
| 2510467 | 10 BRACKET AS | 1 | |
| 5206685 | 11 BRACKET AS | 1 | |
| 3460666 | 12 HARNESS AS-PUMP | 1 | |
| 3499777 | 13 HARNESS AS-PLATFORM | 1 | |
| 3S2093 | STRAP-CABLE | 10 | |
| 9X0196 | TERMINAL AS (16-GA) | 2 | |
| 8T8737 | PLUG-SEAL | 19 | |
| 1257874 | TUBE-HEAT SHRINK (5.72-MM DIA)(5-CM) | ||
| 1257875 | TUBE-HEAT SHRINK (7.44-MM DIA)(15-CM) | ||
| 9X3402 | SOCKET-CONNECTOR (16-GA TO 18-GA) | 66 | |
| 1261768 | SOCKET-CONNECTOR (14-GA TO 16-GA) | 66 | |
| 1261767 | PIN-CONNECTOR (14-GA TO 16-GA) | 10 | |
| 1261768 | SOCKET-CONNECTOR (14-GA TO 16-GA) | 4 | |
| 9X3401 | PIN-CONNECTOR (16-GA TO 18-GA) | 83 | |
| 1261767 | PIN-CONNECTOR (14-GA TO 16-GA) | 83 | |
| 1532620 | PLUG AS-CONNECTOR (54-PIN, BLACK) | 1 | |
| 1636759 | SEAL | 1 | |
| 1636637 | RECEPTACLE AS-CONNECTOR (54-PIN, BLACK) | 1 | |
| 2304009 | PLUG AS-CONNECTOR (12-PIN) | 2 | |
| 4550709 | SEAL-CONNECTOR | 1 | |
| 2304011 | PLUG AS-CONNECTOR (2-PIN) | 1 | |
| 4550704 | SEAL-CONNECTOR | 1 | |
| 2434510 | RECEPTACLE AS-CONNECTOR (12-PIN) | 2 | |
| 2725000 | RECEPTACLE AS-CONNECTOR (12-PIN) | 2 | |
| 4P7581 | 14 CLIP (LADDER) | 2 | |
| 5C7883 | 15 BOLT-SOCKET HEAD (M6X1X16-MM) | 4 | |
| 7X2621 | 16 BOLT (M10X1.5X12-MM) | 3 | |
| 8T4121 | 17 WASHER-HARD (11X21X2.5-MM THK) | 18 | |
| 8T4136 | 18 BOLT (M10X1.5X25-MM) | 2 | |
| 8T4137 | 19 BOLT (M10X1.5X20-MM) | 9 | |
| 8T4179 | 20 BOLT (M12X1.75X20-MM) | 2 | |
| 8T4191 | 21 BOLT (M10X1.5X16-MM) | 4 | |
| 8T4223 | 22 WASHER-HARD (13.5X25.5X3-MM THK) | 2 | |
| 9X8256 | 23 WASHER (6.6X12X2-MM THK) | 4 |
