324-5724 WIRING GP-CONSOLE -LHS/N SFZ1-UP

Group No: 324-5724
Part NumberPart NameQty
3S20931 STRAP-CABLE1
7K11812 STRAP-CABLE2
32457253 HARNESS AS-CONSOLE1
8T8730SOCKET-CONNECTOR (16-GA TO 20-GA)10
3S2093STRAP-CABLE6
7Y3963TERMINAL-BULLET (FEMALE)2
8T8737PLUG-SEAL2
9W0844SOCKET-CONNECTOR (14-GA TO 16-GA)4
1193662TUBE-HEAT SHRINK (10.85-MM DIA)(7-CM)
1257874TUBE-HEAT SHRINK (5.72-MM DIA)(5-CM)
9X3402SOCKET-CONNECTOR (16-GA TO 18-GA)11
1552260KIT-CONNECTING PLUG (3-PIN)1
2304011PLUG AS-CONNECTOR (2-PIN)1
2647029SEAL-CONNECTOR1
2305010PLUG AS-CONNECTOR (6-PIN)1
2647032SEAL-CONNECTOR1
2312295PLUG AS-CONNECTOR (8-PIN)1
2647033SEAL-CONNECTOR1
2388245PLUG AS-CONNECTOR (2-PIN)1
2647029SEAL-CONNECTOR1
2397352PLUG AS-CONNECTOR (6-PIN)1
2647032SEAL-CONNECTOR1
3422972CAP-CONNECTOR (2-PIN)2
3422974CAP-CONNECTOR (6-PIN)1
32457324 BRACKET1
9X20425 SCREW-TRUSS HEAD (M6X1X12-MM) (M6X1X12-MM)2
