Assembly
100%

481-0082 COUNTERWEIGHT GPS/N SFZ1-UP

Group No: 481-0082
Part NumberPart NameQty
14202831 COVER1
34059372 HANDLE1
34059393 PLATE1
56005944 COVER AS1
8T3597NUT-WELD (M12X1.75-THD)5
47239985 STRAP AS2
48727706 COUNTERWEIGHT AS1
48870327 TANK GP-FUEL1
13023218 WASHER (13.5X25.5X3-MM THK)3
16176329 BOLT-SELF-LOCKING (M10X1.5X40-MM)14
3K606010 LOCKNUT (3/8-16-THD)2
8T412111 WASHER-HARD (11X21X2.5-MM THK)16
8T413912 BOLT (M12X1.75X30-MM)2
8T491013 BOLT (M12X1.75X60-MM)3
8T422314 WASHER-HARD (13.5X25.5X3-MM THK)2
508009615 STRAP2
6V880116 NUT (3/8-16-THD)2
553575317 SHEET6
553575418 SHEET2
246264119 PADLOCK GP1
5P8500KEY1
