System And Components
488-7014 DOOR GP-ACCESS -RADIATORS/N SFZ1-UP
Group No: 488-7014
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 8T1578 | 1 PAWL (LATCH) | 1 | |
| 8Y4000 | 2 LATCH AS (T-BAR, COMPARTMENT) | 1 | |
| 5P7036 | 3 SEAL (1.1-M) | ||
| 4887015 | 4 DOOR AS | 1 | |
| 4331945 | 4A HINGE AS | 2 | |
| 6V2370 | RIVET-POP | 6 | |
| 8T3982 | STUD (M6X1X25-MM) | 13 | |
| 1014183 | PLATE | 1 | |
| 4887024 | 5 SCREEN AS | 1 | |
| 1282596 | SEAL (3.1-M) | ||
| 4887025 | 6 SCREEN AS | 1 | |
| 1282596 | SEAL (3.5-M) | ||
| 1429036 | 7 NUT (9/16-18-THD) | 2 | |
| 9X2038 | 8 WASHER (7X19X2-MM THK) | 13 | |
| 8T4136 | 9 BOLT (M10X1.5X25-MM) | 2 | |
| 6V7744 | 10 LOCKNUT (M10X1.5-THD) | 2 | |
| 8T2910 | 11 NUT-WING (M6X1-THD) | 13 | |
| 8T4121 | 12 WASHER-HARD (11X21X2.5-MM THK) | 2 |
