System And Components
492-3606 DOOR GP-ACCESSS/N SFZ1-UP
Group No: 492-3606
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 8T1578 | 1 PAWL (LATCH) | 1 | |
| 8Y4000 | 2 LATCH AS (T-BAR, COMPARTMENT) | 1 | |
| 4923607 | 3 DOOR AS | 1 | |
| 4331945 | 3A HINGE AS | 2 | |
| 4923611 | 4 SCREEN AS | 1 | |
| 4923613 | 5 SCREEN AS | 1 | |
| 1429036 | 6 NUT (9/16-18-THD) | 2 | |
| 6V7744 | 7 LOCKNUT (M10X1.5-THD) | 2 | |
| 8T2910 | 8 NUT-WING (M6X1-THD) | 12 | |
| 8T4121 | 9 WASHER-HARD (11X21X2.5-MM THK) | 2 | |
| 8T4136 | 10 BOLT (M10X1.5X25-MM) | 2 | |
| 9X2038 | 11 WASHER (7X19X2-MM THK) | 12 | |
| 5P7036 | 12 SEAL (0.7-M) |
