System And Components
481-0074 HOOD & GUARD GPS/N SFZ1-UP
Group No: 481-0074
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 4E1384 | 1 BUMPER-CONICAL | 2 | |
| 4I0118 | 2 HOOK AS | 2 | |
| 4I2599 | 3 SOCKET | 1 | |
| 2462641 | 4 PADLOCK GP | 3 | |
| 5P8500 | KEY | 1 | |
| 7Y2853 | 5 SPACER (13X38X5-MM THK) | 4 | |
| 3384068 | 6 SUPPORT AS | 1 | |
| 3384364 | LINER | 1 | |
| 3384115 | 7 BRACKET AS | 3 | |
| 3384209 | 8 SHEET | 1 | |
| 3397383 | 9 SUPPORT AS | 2 | |
| 3397384 | 10 SUPPORT AS | 2 | |
| 3504816 | 11 SHEET AS-SOUND SUPPRESSION | 1 | |
| 3384341 | LINER | 1 | |
| 3568961 | 12 SHEET AS-SOUND SUPPRESSION | 1 | |
| 3568963 | LINER | 1 | |
| 3597995 | 13 SHEET | 1 | |
| 3597996 | 14 SUPPORT AS | 1 | |
| 0543788 | WASHER (13.5X30X3-MM THK) | 2 | |
| 3828630 | 15 ROLLER | 2 | |
| 3852304 | 16 SHEET AS-SOUND SUPPRESSION | 1 | |
| 3852335 | 17 SPRING | 2 | |
| 3988098 | 18 SHEET AS-SOUND SUPPRESSION | 1 | |
| 3988104 | 19 SUPPORT AS | 1 | |
| 3988110 | 20 SUPPORT AS | 1 | |
| 3988111 | 21 SHEET AS-SOUND SUPPRESSION | 1 | |
| 4250003 | 22 SUPPORT AS | 1 | |
| 4250009 | 23 SHEET AS-SOUND SUPPRESSION | 1 | |
| 4309415 | 24 RETAINER | 2 | |
| 4309772 | 25 SUPPORT AS | 1 | |
| 4309777 | 26 COVER AS | 1 | |
| 4I7924 | WASHER (4.5X40X1.2-MM THK) | 5 | |
| 6P2216 | CAP (PUSH ON) | 5 | |
| 3384327 | SILENCER | 1 | |
| 4310088 | 27 SHEET AS-SOUND SUPPRESSION | 1 | |
| 4373103 | 28 ROD AS | 3 | |
| 4380105 | 29 HOOD GP-ENGINE | 1 | |
| 4380115 | 30 PLATE AS | 1 | |
| 4380117 | LINER | 1 | |
| 4838536 | 31 SHEET AS-SOUND SUPPRESSION | 1 | |
| 4882400 | 32 PLATE AS | 2 | |
| 4882401 | 33 PLATE AS | 1 | |
| 4903711 | 34 SHEET AS | 1 | |
| 3384236 | LINER | 1 | |
| 4903714 | 35 SHEET AS-SOUND SUPPRESSION | 1 | |
| 4903717 | 36 SUPPORT AS | 1 | |
| 4914684 | 37 SUPPORT AS | 1 | |
| 5P5649 | SEAL-BULK (1.2-M) | ||
| 4914688 | 38 SUPPORT AS | 1 | |
| 3384371 | LINER | 1 | |
| 4923596 | 39 SUPPORT AS | 1 | |
| 3384195 | LINER | 1 | |
| 3485409 | SEAL (13-DM) | ||
| 4923600 | 40 COVER AS-SOUND SUPPRESSION | 1 | |
| 4923605 | 41 DOOR GP-ACCESS | 1 | |
| 4993859 | 42 DUCT GP-CAB AIR | 1 | |
| 4993866 | 43 SHEET AS | 1 | |
| 4993872 | 44 COVER AS | 1 | |
| 4993876 | 45 COVER AS | 1 | |
| 5032980 | 46 SHEET AS-SOUND SUPPRESSION | 1 | |
| 5034115 | 47 SHEET AS-SOUND SUPPRESSION | 1 | |
| 5117064 | 48 BAR | 1 | |
| 5117066 | 49 SUPPORT GP-HOOD | 1 | |
| 5117070 | 50 SUPPORT AS | 1 | |
| 5173801 | 51 SHEET AS | 1 | |
| 5154508 | 52 SUPPORT AS | 1 | |
| 5178210 | 53 SHEET AS | 1 | |
| 9M2307 | WASHER (5.2X19X2-MM THK) | 5 | |
| 9M5732 | RIVET-POP | 5 | |
| 1019848 | SEAL (0.5-M) | ||
| 3384245 | SHEET-RUBBER | 1 | |
| 5233203 | 54 BAR AS | 1 | |
| 1358573 | 55 BOLT AS | 59 | |
| 1358575 | 56 BOLT AS | 90 | |
| 1703016 | 57 SPACER (19X32X2-MM THK) | 12 | |
| 2447789 | 58 SPACER (19X38X3-MM THK) | 4 | |
| 3445674 | 59 NUT (M8X1.25-THD) | 2 | |
| 3B4615 | 60 PIN-COTTER | 9 | |
| 5P0372 | 61 LOCK PIN | 1 | |
| 5P1076 | 62 WASHER-HARD (13.5X30X4-MM THK) | 6 | |
| 5P4116 | 63 WASHER-HARD (8.8X20.5X2-MM THK) | 8 | |
| 5P8522 | 64 GROMMET | 3 | |
| 6V7673 | 65 BOLT (M12X1.75X50-MM) | 1 | |
| 7Y2854 | 66 SPACER (24X38X3-MM THK) | 4 | |
| 7Y2916 | 67 PIN-CLEVIS | 1 | |
| 8T4121 | 68 WASHER-HARD (11X21X2.5-MM THK) | 21 | |
| 8T4137 | 69 BOLT (M10X1.5X20-MM) | 10 | |
| 8T4138 | 70 BOLT (M6X1X20-MM) | 2 | |
| 8T4183 | 71 BOLT (M12X1.75X40-MM) | 2 | |
| 8T4189 | 72 BOLT (M8X1.25X20-MM) | 8 | |
| 8T4200 | 73 BOLT (M8X1.25X16-MM) | 3 | |
| 8T4223 | 74 WASHER-HARD (13.5X25.5X3-MM THK) | 4 | |
| 8T4224 | 75 WASHER-HARD (8.8X16X2-MM THK) | 3 | |
| 8T4648 | 76 BOLT (M12X1.75X70-MM) | 1 | |
| 8T4910 | 77 BOLT (M12X1.75X60-MM) | 2 | |
| 8T6868 | 78 BOLT (M12X1.75X80-MM) | 1 | |
| 9X8256 | 79 WASHER (6.6X12X2-MM THK) | 2 | |
| 2983112 | 80 HANDRAIL | 1 | |
| 8T4196 | 81 BOLT (M10X1.5X35-MM) | 2 | |
| 5P7211 | 82 SEAL (0.6-M) | ||
| 5P7211 | 82A SEAL (1.4-M) | ||
| 5P7036 | 83 SEAL (1.9-M) |
