System And Components
372-5222 AIR CONDITIONER GPS/N SFZ1-UP
Group No: 372-5222
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1338714 | 1 GROMMET | 1 | |
| 2R8159 | 2 BOLT-SOCKET HEAD (10-32X1.5-IN) | 2 | |
| 3B4501 | 3 LOCKWASHER | 2 | |
| 3E5464 | 4 SWITCH AS-THERMOSTAT (HVAC) | 1 | |
| 3S2093 | 6 STRAP-CABLE | 2 | |
| 8L7905 | 7 RIVET-POP | 4 | |
| 0374838 | 8 CLAMP | 1 | |
| 1143140 | 9 GROMMET | 1 | |
| 2366923 | 10 SWITCH AS-PRESSURE (HIGH, LOW)(REFRIGERANT COMPRESSOR) | 1 | |
| 1313093 | 11 BUSHING | 1 | |
| 1339012 | 12 FUSE (15-AMPERE)(THERMAL) | 1 | |
| 1776689 | 13 PLATE | 1 | |
| 1776690 | 14 PLATE | 1 | |
| 1776692 | 15 PLATE | 1 | |
| 1776694 | 16 PLATE | 1 | |
| 1776696 | 17 GROMMET | 2 | |
| 1776698 | 18 GASKET | 4 | |
| 1776700 | 19 TUBE-DRAIN | 2 | |
| 1776701 | 20 GASKET | 1 | |
| 1776707 | 21 HOUSING | 1 | |
| 1776710 | 22 RING | 1 | |
| 1776711 | 23 DOOR | 1 | |
| 1776726 | 24 TUBE | 1 | |
| 1794673 | 25 GASKET | 1 | |
| 1794674 | 26 GASKET | 1 | |
| 1796136 | 27 GASKET | 1 | |
| 1877719 | 28 SCREW-HEX FLANGE (M5X2.24X14-MM) | 32 | |
| 1892456 | 29 CLIP | 5 | |
| 1910979 | 30 WHEEL-BLOWER | 1 | |
| 1911005 | 31 GASKET | 1 | |
| 1930702 | 32 GASKET | 1 | |
| 2029041 | 33 GASKET | 1 | |
| 2061345 | 34 STRAP-CABLE | 2 | |
| 2082929 | 35 GASKET | 1 | |
| 2289043 | 36 COIL AS-EVAPORATOR | 1 | |
| 2289044 | 37 VALVE | 1 | |
| 2289539 | 38 PLATE | 1 | |
| 2486772 | 39 SCREW-MACHINE (8-16X7.75-IN) | 8 | |
| 2516770 | 40 PLENUM AS | 1 | |
| 8L7905 | RIVET-POP | 2 | |
| 1776699 | GASKET | 1 | |
| 2516773 | 41 BRACKET | 1 | |
| 2575029 | 42 RESISTOR AS | 1 | |
| 2659620 | 43 ACTUATOR (ELECTRONIC) | 1 | |
| 2688769 | 44 VALVE & MOUNTING AS-WATER (HEATER) | 1 | |
| 2844177 | 45 TUBE AS | 1 | |
| 2881556 | 46 MOTOR AS-FAN | 1 | |
| 2951804 | 47 BRACKET AS | 1 | |
| 2982652 | 48 CLIP | 1 | |
| 1193859 | 49 SCREW-PAN HEAD (10-16X0.75-IN) | 2 | |
| 3224474 | 50 FILM-INFORMATION (24-VOLT HEATER) | 1 | |
| 3617535 | 51 TUBE | 1 | |
| 3640672 | 52 COIL AS-HEATER | 1 | |
| 3640891 | 53 PLATE | 1 | |
| 3726092 | 55 GUARD AS | 1 | |
| 3726629 | 56 COVER | 1 | |
| 3735807 | 57 PLATE | 2 | |
| 3742088 | 58 HARNESS AS-HEATER & AIR COND | 1 | |
| 1261768 | SOCKET-CONNECTOR (14-GA TO 16-GA) | 4 | |
| 9X3402 | SOCKET-CONNECTOR (16-GA TO 18-GA) | 4 | |
| 6T6505 | HOUSING-RECEPTACLE (BLADE, POSITIVE LOCK) | 2 | |
| 2305008 | PLUG AS-CONNECTOR (4-PIN) | 1 | |
| 2647031 | SEAL-CONNECTOR | 1 | |
| 1028801 | KIT-RECEPTACLE (12-PIN) | 1 | |
| 6T6506 | TERMINAL-BLADE (14-GA TO 18-GA) | 2 | |
| 8T8729 | PIN-CONNECTOR (16-GA TO 20-GA) | 11 | |
| 8T8730 | SOCKET-CONNECTOR (16-GA TO 20-GA) | 5 | |
| 8T8737 | PLUG-SEAL | 2 | |
| 1006674 | SEAL-CONNECTOR | 2 | |
| 1116792 | TERMINAL-RECEPTACLE (18-GA TO 20-GA) | 2 | |
| 1116793 | TERMINAL-RECEPTACLE (14-GA TO 16-GA) | 6 | |
| 1116795 | HOUSING-RELAY | 2 | |
| 1193662 | TUBE-HEAT SHRINK (10.85-MM DIA)(26-CM) | ||
| 1245640 | TERMINAL-SOCKET | 2 | |
| 1257874 | TUBE-HEAT SHRINK (5.72-MM DIA)(10-CM) | ||
| 5P5618 | TERMINAL-BLADE (10-GA TO 12-GA) | 2 | |
| 1552270 | KIT-CONNECTING PLUG (2-PIN) | 1 | |
| 1552271 | KIT-CONNECTING PLUG (4-PIN) | 1 | |
| 1922112 | SOCKET-TERMINAL | 4 | |
| 4D2297 | 59 SEAL-O-RING | 2 | |
| 5C2890 | 60 NUT (M6X1-THD) | 1 | |
| 5L6688 | 61 BUTTON-PLUG | 2 | |
| 8C7581 | 62 SCREW-MACHINE (M4X0.7X8-MM) | 1 | |
| 8C8457 | 63 SCREW-MACHINE (M5X0.8X14-MM) | 2 | |
| 8T4205 | 64 WASHER-HARD (7.2X14.5X2-MM THK) | 1 | |
| 8T6631 | 65 SCREW-MACHINE (8-32X0.5-IN) | 2 | |
| 9X7378 | 66 SEAL-O-RING | 1 | |
| 9X7380 | 67 SEAL-O-RING | 1 | |
| 9X7381 | 68 SEAL-O-RING | 1 | |
| 9X7382 | 69 SEAL-O-RING | 2 | |
| 5P5639 | 70 SEAL (0.4-M) |
