System And Components
316-8822 CONSOLE GP-OPERATOR -LHS/N SFZ1-UP
Group No: 316-8822
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1282135 | 1 SCREW-TRUSS HEAD (M6X1X13-MM) | 3 | |
| 1282136 | 2 SCREW-TRUSS HEAD (M6X1X16-MM) | 2 | |
| 2346579 | 3 NUT-SPEED | 1 | |
| 2457790 | 4 SCREW-TAPPING (10-16X0.625-IN) | 1 | |
| 3346450 | 5 COVER | 1 | |
| 3346451 | 6 COVER | 1 | |
| 3346455 | 7 SUPPORT AS | 1 | |
| 3835711 | 8 SWITCH GP-POSITION (HYDRAULIC LOCKOUT) | 1 | |
| 3346465 | 9 ARMREST GP (LH) | 1 | |
| 3573845 | 10 COVER AS | 1 | |
| 1709724 | CLIP | 4 | |
| 3346452 | COVER | 1 | |
| 3573846 | 11 COVER AS | 1 | |
| 1709724 | CLIP | 4 | |
| 3346453 | COVER | 1 | |
| 3573848 | 12 COVER AS | 1 | |
| 1709724 | CLIP | 4 | |
| 3346468 | COVER | 1 | |
| 9X2041 | 13 SCREW-TRUSS HEAD (M10X1.5X20-MM) | 3 | |
| 9X2042 | 14 SCREW-TRUSS HEAD (M6X1X12-MM) (M6X1X12-MM) | 3 |
