System And Components
438-0110 RISER GP-CABS/N SFZ1-UP
Group No: 438-0110
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 9X2299 | 1 LATCH AS | 1 | |
| 1224120 | 2 ROD | 1 | |
| 2377735 | 3 DOOR AS-ACCESS | 1 | |
| 1772064 | HINGE AS | 1 | |
| 2377753 | 4 COVER-LIGHT | 2 | |
| 2377754 | 5 PLATE | 2 | |
| 2481456 | 6 PLATE AS | 1 | |
| 2791179 | 7 PLATE | 1 | |
| 4380111 | 8 RISER AS | 1 | |
| 3468184 | 9 PLATE AS | 1 | |
| 3B4618 | 10 PIN-COTTER | 1 | |
| 2A5222 | 11 WASHER (10.3X15.9X1-MM THK) | 4 | |
| 3B8489 | 12 FITTING-GREASE (1/8-27 PTF) | 2 | |
| 5C2890 | 13 NUT (M6X1-THD) | 4 | |
| 5C9553 | 14 BOLT (M6X1X16-MM) | 4 | |
| 6V7357 | 15 BOLT (M6X1X25-MM) | 8 | |
| 8T4121 | 16 WASHER-HARD (11X21X2.5-MM THK) | 9 | |
| 8T4136 | 17 BOLT (M10X1.5X25-MM) | 8 | |
| 8T4223 | 18 WASHER-HARD (13.5X25.5X3-MM THK) | 2 | |
| 8T4956 | 19 BOLT (M12X1.75X35-MM) | 2 | |
| 9X8256 | 20 WASHER (6.6X12X2-MM THK) | 12 | |
| 5P5969 | 21 SEAL (0.01-M EACH) | ||
| 5P5942 | 22 SEAL (0.14-M EACH) | ||
| 5P5942 | 22A SEAL (0.8-M EACH) |
