System And Components
394-4792 LINES GP-FUELS/N EBK1-UP; FBR1-UP
Group No: 394-4792
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 3S2093 | 1 STRAP-CABLE | 1 | |
| 4I0379 | 2 VALVE-MANUAL (FUEL SHUTOFF) | 1 | |
| 7K1181 | 3 STRAP-CABLE | 1 | |
| 7Y8167 | 4 GROMMET (50-MM ID) | 1 | |
| 7Y8168 | 5 GROMMET | 1 | |
| 0932065 | 6 GROMMET | 4 | |
| 1343299 | 7 GROMMET | 2 | |
| 1416526 | 8 GROMMET | 1 | |
| 2609244 | 9 ELBOW | 1 | |
| 3514105 | 10 PLATE AS | 1 | |
| 4830997 | 11 FILTER GP-WATER SEP & FUEL | 1 | |
| 3617347 | 12 CONNECTION GP-FUEL | 2 | |
| 4833870 | 13 BRACKET AS | 1 | |
| 3684691 | LINER | 1 | |
| 3685170 | 14 BRACKET AS | 1 | |
| 3686658 | 15 VALVE | 1 | |
| 5256205 | 16 FILTER-FUEL (IN-LINE)(WATER SEPARATOR) | 1 | |
| 3849223 | 17 TEE AS | 1 | |
| 6V1625 | TEE-O-RING | 1 | |
| 2147568 | SEAL-O-RING | 1 | |
| 3855773 | 18 CONNECTOR AS | 1 | |
| 5P1046 | CONNECTOR | 1 | |
| 2147568 | SEAL-O-RING | 1 | |
| 3964411 | 19 HOSE | 1 | |
| 4216152 | 20 HOSE | 1 | |
| 4216218 | 21 HOSE AS | 1 | |
| 3550633 | COUPLER-QUICK DISCONNECT | 2 | |
| 4216219 | 22 HOSE AS | 1 | |
| 4216222 | 23 HOSE AS | 1 | |
| 4465409 | 24 PUMP AS-FUEL TRANSFER (24-VOLT) | 1 | |
| 4525715 | 26 HOSE AS | 1 | |
| 1358573 | 27 BOLT AS | 2 | |
| 2147568 | 28 SEAL-O-RING | 2 | |
| 2385080 | 29 SEAL-O-RING | 1 | |
| 2385081 | 30 SEAL-O-RING | 1 | |
| 2977964 | 31 CONNECTOR | 1 | |
| 3295459 | 32 ADAPTER AS | 1 | |
| 5P1404 | ADAPTER | 1 | |
| 2385081 | SEAL-O-RING | 1 | |
| 3432385 | 33 CLIP (LOOP) | 2 | |
| 3474416 | 34 ADAPTER | 2 | |
| 3514318 | 35 CLIP (LOOP) | 14 | |
| 3514319 | 36 CLIP (LOOP) | 3 | |
| 3514320 | 37 CLIP (LOOP) | 13 | |
| 5P4325 | 38 CLIP (LOOP) | 1 | |
| 5P4924 | 39 ELBOW | 1 | |
| 6K8180 | 40 GROMMET | 2 | |
| 6S8620 | 41 CLAMP-HOSE | 13 | |
| 6V4292 | 42 ELBOW | 1 | |
| 7V6571 | 43 GROMMET | 3 | |
| 8T1889 | 44 CLIP (SLOT) | 3 | |
| 8T1890 | 45 CLIP (TAB) | 3 | |
| 8T4121 | 46 WASHER-HARD (11X21X2.5-MM THK) | 42 | |
| 8T4136 | 47 BOLT (M10X1.5X25-MM) | 19 | |
| 8T4137 | 48 BOLT (M10X1.5X20-MM) | 16 | |
| 8T4195 | 49 BOLT (M10X1.5X30-MM) | 4 | |
| 8T4196 | 50 BOLT (M10X1.5X35-MM) | 3 | |
| 8T4224 | 51 WASHER-HARD (8.8X16X2-MM THK) | 3 | |
| 9P0719 | 52 GROMMET | 1 | |
| 7X0818 | 53 BOLT (M8X1.25X45-MM) | 3 | |
| 8C3681 | 54 HOSE-DRAIN (40-CM) | ||
| 3478646 | 55 HOSE (43-CM) | ||
| 3478645 | 56 HOSE (144-CM) | ||
| 3478645 | 56A HOSE (55-CM) | ||
| 3478645 | 56B HOSE (40-CM) |
