System And Components
Assembly
100%

324-5711 BATTERY & WIRING GP -COLD WEATHER, WITH JUMP STARTS/N EBK1-UP; FBR1-UP

Group No: 324-5711
Part NumberPart NameQty
5I82701 COVER-BATTERY1
6W60052 HOLD-DOWN-BATTERY1
35082813 SUPPORT AS-BATTERY1
34854093A SEAL (1-DM EACH)
34854103B SEAL (1-DM)
23825014 KNOB1
23825285 ROD1
26395746 BATTERY AS (12-VOLT, MAINTENANCE FREE)2
1231373CAP AS-FILLER (7/8-9-THD)6
32801328 CABLE AS1
9G0002COVER AS-TERMINAL (RED)1
8L8413STRAP-CABLE (WHITE)1
9G0005COVER AS-TERMINAL (BLACK)1
8L8413STRAP-CABLE (WHITE)1
8C5918TERMINAL AS-BATTERY (NEGATIVE)1
1M6119BOLT (5/16-18X1.375-IN)1
1M6120NUT (5/16-18-THD)1
8T9756TERMINAL AS-BATTERY (POSITIVE)1
1M6119BOLT (5/16-18X1.375-IN)1
1M6120NUT (5/16-18-THD)1
1598049CABLE (00-GA, RED)(31-CM)
35082829 CABLE AS1
1S7251TERMINAL-CABLE (00-GA, 1/2-IN SCREW)1
9G0004COVER AS-TERMINAL (RED)(BATTERY POSITIVE)1
8L8413STRAP-CABLE (WHITE)1
8C5917TERMINAL AS-BATTERY (POSITIVE)1
1M6119BOLT (5/16-18X1.375-IN)1
1M6120NUT (5/16-18-THD)1
1598049CABLE (00-GA, RED)(38-CM)
3010091COVER-TERMINAL (RED)(JUNCTION BLOCK)1
350828310 CABLE AS1
1S7251TERMINAL-CABLE (00-GA, 1/2-IN SCREW)1
9G0005COVER AS-TERMINAL (BLACK)(BATTERY NEGATIVE)1
8L8413STRAP-CABLE (WHITE)1
9G8909COVER-TERMINAL (BLACK)(JUNCTION BLOCK)1
8C5918TERMINAL AS-BATTERY (NEGATIVE)1
1M6119BOLT (5/16-18X1.375-IN)1
1M6120NUT (5/16-18-THD)1
1598050CABLE (00-GA, BLACK)(49-CM)
5C726111 NUT (M8X1.25-THD)1
8T413313 NUT (M10X1.5-THD)1
8T422314 WASHER-HARD (13.5X25.5X3-MM THK)4
8T419215 BOLT (M12X1.75X25-MM)4
8T422618 WASHER-PLATED (10.5X45X3-MM THK)1
