System And Components
349-5515 SENSOR & MTG GP-POSITION -GRADE CONTROL, BOOMS/N FBR1-UP
Group No: 349-5515
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1448073 | 1 LOCKWASHER | 1 | |
| 3451948 | 2 SENSOR GP-POSITION (ROTARY)(STICK) | 1 | |
| 3495427 | 3 SPACER (5-MM THK) | 1 | |
| 3495508 | 4 LEVER | 1 | |
| 3495533 | 5 PLATE | 1 | |
| 3495542 | 6 HOLDER | 1 | |
| 3495543 | 7 BRACKET AS | 1 | |
| 1053487 | 8 BOLT-SOCKET HEAD (M6X1X20-MM) | 1 | |
| 1313983 | 9 BOLT-SOCKET HEAD (M8X1.25X35-MM) | 4 | |
| 5C9553 | 10 BOLT (M6X1X16-MM) | 2 | |
| 8T4121 | 11 WASHER-HARD (11X21X2.5-MM THK) | 3 | |
| 8T4137 | 12 BOLT (M10X1.5X20-MM) | 1 | |
| 8T4191 | 13 BOLT (M10X1.5X16-MM) | 2 | |
| 8T4224 | 14 WASHER-HARD (8.8X16X2-MM THK) | 4 | |
| 9X8256 | 15 WASHER (6.6X12X2-MM THK) | 2 |
