System And Components
492-4152 SENSOR GP-ENGINES/N D8T1-UP
Group No: 492-4152
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1243815 | 1 BOLT (M8X1.25X16-MM) | 7 | |
| 1999252 | 2 SEAL-O-RING | 2 | |
| 1999267 | 3 SEAL-O-RING | 4 | |
| 1999751 | 4 SEAL-O-RING | 1 | |
| 2179039 | 5 STRAP-CABLE | 5 | |
| 2566454 | 6 SENSOR-TEMPERATURE (2-PIN)(COOLANT) | 1 | |
| 2566454 | 6A SENSOR-TEMPERATURE (2-PIN)(INTAKE MANIFOLD AIR) | 1 | |
| 2765603 | 7 SEAL-O-RING | 1 | |
| 3203060 | 8 SENSOR GP-PRESSURE (ENGINE OIL PRESSURE) | 1 | |
| 3203061 | 9 SENSOR GP-PRESSURE (AIR INLET MANIFOLD) | 1 | |
| 3203062 | 10 SENSOR GP-PRESSURE (COOLED EXHAUST GAS) | 1 | |
| 3203063 | 11 SENSOR GP-PRESSURE (ATMOSPHERIC) | 1 | |
| 3308196 | 12 SEAL-O-RING | 1 | |
| 3327865 | 13 TIE-CABLE | 2 | |
| 3398822 | 14 SENSOR AS-TEMPERATURE (NOX REDUCTION SYSTEM) | 1 | |
| 2818802 | 14A RECEPTACLE AS-CONNECTOR (2-PIN) | 1 | |
| 3589934 | 15 UNION | 2 | |
| 3691202 | 16 BRACKET AS | 1 | |
| 3850697 | 17 CLAMP | 2 | |
| 3851174 | 18 SENSOR GP-PRESSURE (NRS OUTLET) | 1 | |
| 3854319 | 19 PIPE AS | 1 | |
| 3308196 | 19A SEAL-O-RING | 2 | |
| 3854320 | 20 PIPE AS | 1 | |
| 3308196 | 20A SEAL-O-RING | 2 | |
| 3887638 | 21 MANIFOLD AS | 1 | |
| 2956661 | 21A PLUG | 1 | |
| 4162211 | 22 SENSOR GP-TEMPERATURE (EXHAUST) | 1 | |
| 4223830 | 23 HARNESS AS-SENSOR | 1 | |
| 4224876 | 24 BRACKET | 1 | |
| 6I0254 | 25 BOLT (M8X1.25X30-MM) | 3 | |
| 2380120 | 26 SENSOR GP-SPEED (CRANKSHAFT) | 1 | |
| 2380120 | 26A SENSOR GP-SPEED (CAMSHAFT) | 1 | |
| 2284947 | 27 SEAL-O-RING | 2 | |
| 2323861 | 28 PLUG (BLANKING) | 1 | |
| 8T7547 | 29 BOLT (M8X1.25X30-MM) | 2 |
