System And Components
480-7390 WIRING GP-FRONT -GRADE CONTROL, STICKS/N FBR1-UP
Group No: 480-7390
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 3S2093 | 1 STRAP-CABLE | 14 | |
| 7K1181 | 2 STRAP-CABLE | 2 | |
| 4784298 | 3 HARNESS AS-CONTROL (STICK) | 1 | |
| 8T8729 | PIN-CONNECTOR (16-GA TO 20-GA) | 1 | |
| 3E5165 | CAP AS-PROTECTION | 1 | |
| 8L8413 | STRAP-CABLE (WHITE) | 1 | |
| 8T8737 | PLUG-SEAL | 4 | |
| 1257874 | TUBE-HEAT SHRINK (5.72-MM DIA)(25-CM) | ||
| 1257875 | TUBE-HEAT SHRINK (7.44-MM DIA)(5-CM) | ||
| 9X3402 | SOCKET-CONNECTOR (16-GA TO 18-GA) | 3 | |
| 9X3401 | PIN-CONNECTOR (16-GA TO 18-GA) | 8 | |
| 1552271 | KIT-CONNECTING PLUG (4-PIN) | 1 | |
| 2434510 | RECEPTACLE AS-CONNECTOR (12-PIN) | 1 | |
| 2435362 | CAP-DUST | 1 | |
| 2532695 | PLUG AS-CONNECTOR (6-PIN) | 1 | |
| 3034244 | RECEPTACLE AS-CONNECTOR | 1 | |
| 4P7581 | 4 CLIP (LADDER) | 2 | |
| 8T4121 | 5 WASHER-HARD (11X21X2.5-MM THK) | 2 | |
| 8T4191 | 6 BOLT (M10X1.5X16-MM) | 2 | |
| 5P8522 | 7 GROMMET | 1 |
