System And Components
337-2520 LINES GP-STICK CYLINDER -STICK LOAD CONTROLS/N FBR1-UP
Group No: 337-2520
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 0931294 | 1 CLAMP | 2 | |
| 1192325 | 2 SUPPORT AS | 2 | |
| 1795203 | 3 SUPPORT AS | 2 | |
| 1795235 | 4 CLIP | 4 | |
| 3350406 | 5 VALVE GP-LOAD CONTROL (STICK CYLINDER) | 1 | |
| 2479321 | 6 TUBE AS | 1 | |
| 2479322 | 7 TUBE AS | 1 | |
| 2479324 | 8 TUBE AS | 1 | |
| 2479326 | 9 TUBE AS | 1 | |
| 1081782 | 10 BOLT-SOCKET HEAD (M12X1.75X90-MM) | 4 | |
| 1488328 | 11 CONNECTOR AS | 1 | |
| 3D2824 | SEAL-O-RING | 1 | |
| 6V8398 | SEAL-O-RING | 1 | |
| 6V8633 | CONNECTOR | 1 | |
| 1488368 | 12 ELBOW AS | 2 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 4J5477 | SEAL-O-RING | 1 | |
| 6V8627 | ELBOW | 1 | |
| 1P3703 | 13 SEAL-RECTANGULAR | 1 | |
| 1P3704 | 14 SEAL-RECTANGULAR | 1 | |
| 5K9090 | 15 SEAL-O-RING | 1 | |
| 6V8397 | 16 SEAL-O-RING | 2 | |
| 6V8398 | 17 SEAL-O-RING | 1 | |
| 8T4121 | 18 WASHER-HARD (11X21X2.5-MM THK) | 10 | |
| 8T4139 | 19 BOLT (M12X1.75X30-MM) | 4 | |
| 8T4186 | 20 BOLT (M10X1.5X40-MM) | 2 | |
| 8T4196 | 21 BOLT (M10X1.5X35-MM) | 8 | |
| 8T4223 | 22 WASHER-HARD (13.5X25.5X3-MM THK) | 8 | |
| 8T4648 | 23 BOLT (M12X1.75X70-MM) | 4 |
