Assembly
100%

337-2520 LINES GP-STICK CYLINDER -STICK LOAD CONTROLS/N FBR1-UP

Group No: 337-2520
Part NumberPart NameQty
1P37031 SEAL-RECTANGULAR1
1P37042 SEAL-RECTANGULAR1
5K90903 SEAL-O-RING1
6V83974 SEAL-O-RING2
6V97465 SEAL-O-RING1
8T41216 WASHER-HARD (11X21X2.5-MM THK)10
8T41397 BOLT (M12X1.75X30-MM)4
8T41868 BOLT (M10X1.5X40-MM)2
8T41969 BOLT (M10X1.5X35-MM)8
8T422310 WASHER-HARD (13.5X25.5X3-MM THK)8
8T464811 BOLT (M12X1.75X70-MM)4
093129412 CLAMP2
108178213 BOLT-SOCKET HEAD (M12X1.75X90-MM)4
119232514 SUPPORT AS2
148832715 CONNECTOR AS1
3D2824SEAL-O-RING1
6V8637CONNECTOR1
6V9746SEAL-O-RING1
148836816 ELBOW AS2
3J1907SEAL-O-RING1
4J5477SEAL-O-RING1
6V8627ELBOW1
247932117 TUBE AS1
247932418 TUBE AS1
247932619 TUBE AS1
335040620 VALVE GP-LOAD CONTROL (STICK CYLINDER)1
540336621 SUPPORT AS2
540336822 TUBE AS1
4I167623 CLIP4
