System And Components
513-6905 MANIFOLD GP-EXHAUSTS/N D8T1-UP
Group No: 513-6905 · Commonality
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1068916 | 1 BOLT (M6X1X16-MM) | 2 | |
| 1243815 | 2 BOLT (M8X1.25X16-MM) | 1 | |
| 1475553 | 3 STUD (M10X1.5X40-MM) | 4 | |
| 3574390 | 4 CONNECTOR AS | 1 | |
| 8T7489 | 4A CONNECTOR | 1 | |
| 2287089 | 4B SEAL-O-RING | 1 | |
| 2287101 | 4C SEAL-O-RING | 1 | |
| 1984765 | 5 WASHER-HARD (8.8X20X8-MM THK) | 2 | |
| 2321295 | 6 PLUG | 2 | |
| 2388292 | 7 BOLT-FLANGE HEAD | 12 | |
| 2780017 | 8 GASKET | 1 | |
| 2867851 | 9 SPACER | 12 | |
| 3161164 | 10 WASHER | 2 | |
| 3533440 | 11 MANIFOLD | 1 | |
| 3570617 | 12 GASKET | 1 | |
| 3717601 | 13 GASKET | 2 | |
| 4578672 | 14 BOLT (M10X1X22-MM) | 1 | |
| 4851043 | 15 HOSE & TUBE AS | 1 | |
| 4872929 | 16 LINE AS-OIL | 1 | |
| 2693086 | 16A CLAMP-BAND | 2 | |
| 5014145 | 17 BRACKET AS | 1 | |
| 6I0217 | 18 BOLT (M8X1.25X20-MM) | 3 | |
| 6I0260 | 19 BOLT (M8X1.25X25-MM) | 2 |
