Assembly
100%

395-3426 LINES GP-COOLINGS/N DPL1-UP

Group No: 395-3426
Part NumberPart NameQty
32639691 PIPE AS (AFTERCOOLER, LOW TEMPERATURE)1
32639732 HOSE-RADIATOR (UPPER)1
32639743 HOSE-RADIATOR (LOWER)1
35450974 PIPE AS (AFTERCOOLER, HIGH TEMPERATURE)1
35450995 HOSE (AFTERCOOLER, HIGH TEMPERATURE)1
35451066 HOSE (AFTERCOOLER, HIGH TEMPERATURE)1
36922317 HOSE (AFTERCOOLER, LOW TEMPERATURE)1
39712178 PIPE AS (AFTERCOOLER, HIGH TEMPERATURE)1
14403679 CLAMP-HOSE2
184539410 CLIP (LOOP)1
5M621311 PLUG-PIPE (1/4-18-THD)1
5P107612 WASHER-HARD (13.5X30X4-MM THK)2
5P411613 WASHER-HARD (8.8X20.5X2-MM THK)6
8T412114 WASHER-HARD (11X21X2.5-MM THK)1
8T413715 BOLT (M10X1.5X20-MM)1
8T413916 BOLT (M12X1.75X30-MM)2
8T418917 BOLT (M8X1.25X20-MM)6
8T498418 CLAMP-HOSE10
