System And Components
501-0918 WIRING GP-CHASSIS -REFUELING PUMPS/N DPL1-UP
Group No: 501-0918
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 3S2093 | 1 STRAP-CABLE | 17 | |
| 7K1181 | 2 STRAP-CABLE | 12 | |
| 9X3495 | 3 CLIP AS | 1 | |
| 1160118 | 4 CLIP | 1 | |
| 3508388 | 5 SPACER (11X25X65-MM THK) | 1 | |
| 5009143 | 6 HARNESS AS-SWITCH (REFUELING PUMP) | 1 | |
| 8T8729 | PIN-CONNECTOR (16-GA TO 20-GA) | 3 | |
| 8T8730 | SOCKET-CONNECTOR (16-GA TO 20-GA) | 3 | |
| 9W0852 | PIN-CONNECTOR (14-GA TO 16-GA) | 1 | |
| 9W0844 | SOCKET-CONNECTOR (14-GA TO 16-GA) | 1 | |
| 1552271 | KIT-CONNECTING PLUG (4-PIN) | 1 | |
| 2434507 | RECEPTACLE AS-CONNECTOR (4-PIN) | 1 | |
| 5010917 | 7 HARNESS AS-CHASSIS | 1 | |
| 8T8729 | PIN-CONNECTOR (16-GA TO 20-GA) | 2 | |
| 8T8730 | SOCKET-CONNECTOR (16-GA TO 20-GA) | 3 | |
| 3S2093 | STRAP-CABLE | 1 | |
| 9W0852 | PIN-CONNECTOR (14-GA TO 16-GA) | 1 | |
| 9W0844 | SOCKET-CONNECTOR (14-GA TO 16-GA) | 1 | |
| 1160126 | HOUSING-PLUG | 1 | |
| 1160128 | SEAL | 1 | |
| 1160255 | TERMINAL-BLADE (10-GA TO 20-GA) | 2 | |
| 1193662 | TUBE-HEAT SHRINK (10.85-MM DIA)(7-CM) | ||
| 2L8069 | TERMINAL-RING (2-GA TO 10-GA, 3/8-IN SCREW) | 1 | |
| 2305008 | PLUG AS-CONNECTOR (4-PIN) | 1 | |
| 4550706 | SEAL-CONNECTOR | 1 | |
| 2434506 | RECEPTACLE AS-CONNECTOR (3-PIN) | 1 | |
| 1325789 | 8 CLIP (LADDER) | 2 | |
| 4P7581 | 9 CLIP (LADDER) | 1 | |
| 7X2621 | 10 BOLT (M10X1.5X12-MM) | 1 | |
| 8T4121 | 11 WASHER-HARD (11X21X2.5-MM THK) | 3 | |
| 8T4137 | 12 BOLT (M10X1.5X20-MM) | 1 | |
| 8T4178 | 13 BOLT (M10X1.5X90-MM) | 1 |
