System And Components
343-0621 LINES GP-AIR -NOX REDUCTION SYSTEMS/N T4F7539-UP
Group No: 343-0621
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 9N5085 | 1 CLAMP | 2 | |
| 3287546 | 2 HOSE | 1 | |
| 4503124 | 3 TUBE-AIR | 1 | |
| 3448272 | 4 TUBE AS-AIR | 1 | |
| 4503123 | 5 FLANGE | 1 | |
| 3537173 | 6 TUBE-VENTURI | 1 | |
| 1092332 | 7 SEAL-O-RING | 2 | |
| 2722583 | 8 SEAL-O-RING | 1 | |
| 3147599 | 9 CLAMP-BAND | 2 | |
| 3E4352 | 10 WASHER-HARD (8.8X20.5X2.5-MM THK) | 3 | |
| 6V2317 | 11 BOLT (M8X1.25X30-MM) | 2 | |
| 8T0100 | 12 BOLT (M8X1.25X60-MM) | 2 | |
| 9M1974 | 13 WASHER-HARD (8.8X16X2-MM THK) | 2 | |
| 5P5757 | 14 SEAL-O-RING | 1 | |
| 4837224 | 15 RETAINER | 1 |
