System And Components
381-6614 CONSOLE GP-OPERATORS/N NMA1-UP
Group No: 381-6614
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 2552752 | 1 SWITCH GP-START (IGNITION) | 1 | |
| 7T6799 | NUT-MOUNTING (1-32-THD) | 1 | |
| 8T8729 | PIN-CONNECTOR (16-GA TO 20-GA) | 5 | |
| 8T8737 | PLUG-SEAL | 1 | |
| 1028805 | KIT-RECEPTACLE (6-PIN) | 1 | |
| 5C9553 | 2 BOLT (M6X1X16-MM) | 4 | |
| 7X2536 | 3 BOLT (M8X1.25X14-MM) | 11 | |
| 8T4189 | 4 BOLT (M8X1.25X20-MM) | 5 | |
| 8T4908 | 5 BOLT (M8X1.25X25-MM) | 2 | |
| 6V2689 | 6 TUBE-HEAT SHRINK (6.35-MM DIA)(0.1-M) | ||
| 3S2093 | 7 STRAP-CABLE | 1 | |
| 5C2874 | 8 NUT (M5X0.8-THD) | 9 | |
| 5P4116 | 9 WASHER-HARD (8.8X20.5X2-MM THK) | 10 | |
| 5P8500 | 10 KEY | 2 | |
| 6V9672 | 11 SCREW-MACHINE (M4X0.7X16-MM) | 2 | |
| 7K1181 | 12 STRAP-CABLE | 13 | |
| 8C8560 | 13 SCREW-LOCK (4-40X0.5-IN) | 4 | |
| 8T0328 | 14 WASHER-HARD (5.5X10X1-MM THK) | 9 | |
| 8T2659 | 15 LOCKNUT (M4X0.7-THD) | 2 | |
| 8T4224 | 16 WASHER-HARD (8.8X16X2-MM THK) | 8 | |
| 9X2042 | 17 SCREW-TRUSS HEAD (M6X1X12-MM) | 4 | |
| 9X8256 | 18 WASHER (6.6X12X2-MM THK) | 4 | |
| 0860507 | 19 PIN | 2 | |
| 0966166 | 20 WASHER-HARD (4.5X9X1-MM THK) | 2 | |
| 1272170 | 21 SCREW-TRUSS HEAD (M8X1.25X20-MM) | 8 | |
| 1328488 | 22 NUT-RING | 1 | |
| 1566175 | 23 CLIP (LADDER) | 3 | |
| 2039007 | 24 NUT (1-1/2-18-THD) | 1 | |
| 2167352 | 25 SCREW-TRUSS HEAD (M8X1.25X30-MM) | 2 | |
| 2321792 | 26 HORN (24-VOLT TO 12-VOLT) | 1 | |
| 2365149 | 27 WASHER-NYLON (11.17X19.05X1.6MM THK) | 2 | |
| 2702679 | 28 LOCKWASHER | 1 | |
| 3445674 | 29 NUT (M8X1.25-THD) | 2 | |
| 3447618 | 30 COVER-SEAL | 1 | |
| 3502929 | 31 INCLINOMETER | 1 | |
| 3679470 | 32 SWITCH AS-PUSH BUTTON (EMERGENCY STOP) | 1 | |
| 1028804 | KIT-RECEPTACLE (4-PIN) | 1 | |
| 3E3377 | WEDGE-RECEPTACLE LOCK (4-PIN) | 1 | |
| 9X3401 | PIN-CONNECTOR (16-GA TO 18-GA) | 4 | |
| 3684778 | 33 FILM-WARNING (EMERGENCY STOP) | 1 | |
| 3950256 | 34 SWITCH AS-HORN | 1 | |
| 1028802 | KIT-RECEPTACLE (2-PIN) | 1 | |
| 9X3401 | PIN-CONNECTOR (16-GA TO 18-GA) | 2 | |
| 1261767 | PIN-CONNECTOR (14-GA TO 16-GA) | 2 | |
| 3983073 | 35 CABLE AS | 1 | |
| 3314222 | KIT-CONNECTING PLUG (12-PIN) | 1 | |
| 3447617 | RECEPTACLE AS | 1 | |
| 1690705 | PLUG-SEAL | 8 | |
| 9X3402 | SOCKET-CONNECTOR (16-GA TO 18-GA) | 4 | |
| 1261768 | SOCKET-CONNECTOR (14-GA TO 16-GA) | 4 | |
| 1257876 | TUBE-HEAT SHRINK (17.78-MM DIA)(3-CM) | ||
| 1552258 | WEDGE-PLUG LOCK (12-PIN) | 1 | |
| 4486966 | 36 CABLE AS (WORK AREA VISUAL SYSTEM) | 1 | |
| 4592234 | 37 MONITOR GP-OPERATOR | 1 | |
| 4707126 | 38 FILM-IDENTIFICATION (IGNITION SWITCH, READ OMM) | 1 | |
| 4918261 | 39 CONSOLE | 1 | |
| 4941267 | 40 BRACKET | 1 | |
| 4941319 | 41 VISOR | 1 | |
| 5045071 | 42 TRAY | 1 | |
| 5155379 | 43 MODULE GP-KEYPAD | 1 | |
| 8T2659 | LOCKNUT (M4X0.7-THD) | 4 | |
| 8F1326 | WASHER (4.2X9.5X0.8-MM THK) | 4 | |
| 5197998 | 44 HARNESS AS-CONSOLE | 1 | |
| 5211927 | 45 BRACKET | 1 | |
| 5212928 | 46 PLATE AS | 1 | |
| 8T3612 | NUT-WELD (M8X1.25-THD) | 2 | |
| 5212954 | 47 ROD AS | 2 | |
| 8T3612 | NUT-WELD (M8X1.25-THD) | 1 | |
| 5214279 | 48 BRACKET | 1 | |
| 5214495 | 49 BRACKET | 1 | |
| 5214496 | 50 BRACKET | 1 | |
| 5516332 | 51 MODULE GP-KEYPAD | 1 | |
| 4472041 | SCREW-PAN HEAD | 8 | |
| 5516329 | SWITCH AS-ROCKER | 2 | |
| 1538003 | 52 BOLT-SOCKET HEAD (M4X0.7X30-MM) | 2 |
