System And Components
479-1698 BATTERY & WIRING GPPART OF 473-2856 ELECTRICAL AR
Group No: 479-1698
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 3E8320 | 1 PLATE-INSTRUCTION (BATTERY) | 1 | |
| 8R0768 | 2 ROD-RETAINING | 2 | |
| 1343355 | 3 STRAP AS | 2 | |
| 1597466 | 4 ANGLE AS | 1 | |
| 2749872 | 5 FUSE (30-AMPERE) | 1 | |
| 2749877 | 6 FUSE (50-AMPERE) | 2 | |
| 2750570 | 7 BAR-BUS | 1 | |
| 2786377 | 8 FUSE (40-AMPERE) | 1 | |
| 3781011 | 9 HOLDER AS-FUSE | 1 | |
| 3781012 | 9A FUSE (100-AMPERE) | 1 | |
| 3781013 | COVER | 3 | |
| 3968366 | FUSE (50-AMPERE) | 1 | |
| 4447809 | 10 RELAY AS (12-VOLT)(GLOW PLUG) | 1 | |
| 4447809 | 10A RELAY AS (12-VOLT)(STARTER) | 1 | |
| 2675211 | SEAL | 1 | |
| 2675213 | COVER | 1 | |
| 4559921 | 11 PLATE | 1 | |
| 4592894 | 12 CABLE AS | 1 | |
| 1S7252 | TERMINAL-CABLE (00-GA, 3/8-IN SCREW) | 2 | |
| 9G8909 | COVER-TERMINAL (BLACK) | 2 | |
| 1598050 | CABLE (00-GA, BLACK)(23-CM) | ||
| 4617843 | 13 PLATE AS | 1 | |
| 6V9632 | NUT-WELD (M6X1-THD) | 2 | |
| 9X2032 | NUT-WELD (M4X0.7-THD) | 4 | |
| 4617845 | 14 PLATE AS | 1 | |
| 8T3612 | NUT-WELD (M8X1.25-THD) | 2 | |
| 1788507 | PLATE-WELD | 1 | |
| 4759185 | 15 CABLE AS-POWER | 1 | |
| 8N0869 | COVER-TERMINAL (RED) | 1 | |
| 0301708 | TERMINAL-RING (0-GA) | 2 | |
| 1598047 | CABLE-ELECTRICAL (0-GA, RED)(66-CM) | ||
| 4760360 | 16 CABLE AS-POWER | 1 | |
| 0301708 | TERMINAL-RING (0-GA) | 2 | |
| 1598047 | CABLE-ELECTRICAL (0-GA, RED)(13-CM) | ||
| 5034111 | 17 CABLE AS-BATTERY (POSITIVE) | 1 | |
| 1M6120 | NUT (5/16-18-THD) | 1 | |
| 1M6119 | BOLT (5/16-18X1.375-IN) | 1 | |
| 1598049 | CABLE (00-GA, RED)(183-CM) | ||
| 8N0869 | COVER-TERMINAL (RED) | 1 | |
| 9X4519 | BOOT (RED) | 1 | |
| 3633484 | TERMINAL-RING | 2 | |
| 4796495 | 18 CABLE AS-BATTERY (NEGATIVE) | 1 | |
| 4D1248 | TERMINAL (00-GA, 3/8-IN SCREW) | 1 | |
| 9G0005 | COVER AS-TERMINAL (BLACK) | 1 | |
| 8L8413 | STRAP-CABLE (WHITE) | 1 | |
| 8C5918 | TERMINAL AS-BATTERY (NEGATIVE) | 1 | |
| 1M6119 | BOLT (5/16-18X1.375-IN) | 1 | |
| 1M6120 | NUT (5/16-18-THD) | 1 | |
| 1598050 | CABLE (00-GA, BLACK)(25-CM) | ||
| 2602998 | COVER-TERMINAL (00-GA, BLACK) | 1 | |
| 0966166 | 19 WASHER-HARD (4.5X9X1-MM THK) | 4 | |
| 1028703 | 20 PLATE-COVER | 2 | |
| 1074749 | 21 PLATE | 3 | |
| 1152422 | 22 BATTERY GP (12-VOLT, MAINTENANCE FREE, WET) | 1 | |
| 1231373 | CAP AS-FILLER (7/8-9-THD) | 6 | |
| 1285531 | 23 CLAMP-HALF | 6 | |
| 1313540 | 24 LOCKNUT (M8X1.25-THD) | 2 | |
| 1565306 | 25 CLAMP-HALF | 4 | |
| 1772215 | 26 STRAP-DUAL CLAMP | 1 | |
| 2088469 | 27 LOCKNUT (M6X1-THD) | 1 | |
| 2323121 | 28 NUT (M10X1.25-THD) | 1 | |
| 2643617 | 29 LOCKWASHER | 2 | |
| 3445674 | 30 NUT (M8X1.25-THD) | 1 | |
| 5C7261 | 32 NUT (M8X1.25-THD) | 4 | |
| 5P4116 | 33 WASHER-HARD (8.8X20.5X2-MM THK) | 3 | |
| 7N0718 | 34 SWITCH GP-DISCONNECT (BATTERY) | 1 | |
| 7P1695 | 35 WASHER (10.5X19X3-MM THK) | 4 | |
| 7X2533 | 36 BOLT (M6X1X35-MM) | 6 | |
| 7X2534 | 37 BOLT (M6X1X50-MM) | 2 | |
| 7X2537 | 38 BOLT (M8X1.25X35-MM) | 1 | |
| 8C5748 | 39 BOLT (M8X1.25X55-MM) | 1 | |
| 8F7242 | 40 WASHER (8.7X15.9X1.6-MM THK) | 5 | |
| 8T4133 | 42 NUT (M10X1.5-THD) | 3 | |
| 8T4189 | 43 BOLT (M8X1.25X20-MM) | 6 | |
| 8T4224 | 44 WASHER-HARD (8.8X16X2-MM THK) | 8 | |
| 8T4908 | 45 BOLT (M8X1.25X25-MM) | 2 | |
| 8T9405 | 46 BOLT-SOCKET HEAD (M4X0.7X16-MM) | 4 | |
| 9X8256 | 47 WASHER (6.6X12X2-MM THK) | 2 |
