System And Components
478-4138 WIRING GP-CANOPYPOWER
Group No: 478-4138
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 7K1181 | 1 STRAP-CABLE | 12 | |
| 1313201 | 2 BOOT | 3 | |
| 2418367 | 3 SWITCH AS-MAGNETIC (12-VOLT)(MAIN POWER RELAY) | 1 | |
| 4F2294 | NUT-JAM (5/16-24-THD) | 2 | |
| 8T8730 | SOCKET-CONNECTOR (16-GA TO 20-GA) | 2 | |
| 1552270 | KIT-CONNECTING PLUG (2-PIN) | 1 | |
| 2659984 | 4 BRACKET | 1 | |
| 2905562 | 5 MOUNT (DUAL SWIVEL) | 1 | |
| 3083527 | 6 SWITCH AS-TOGGLE (CANOPY) | 1 | |
| 8T8729 | PIN-CONNECTOR (16-GA TO 20-GA) | 6 | |
| 1028805 | KIT-RECEPTACLE (6-PIN) | 1 | |
| 4808519 | 8 HARNESS AS-WIRING (CANOPY) | 1 | |
| 4842560 | 9 HARNESS AS-WIRING (FUSE) | 1 | |
| 9G4343 | TERMINAL-RING (4-GA, 1/4-IN SCREW) | 1 | |
| 5P3454 | TERMINAL-RING (4-GA, 5/16-IN SCREW) | 1 | |
| 9G4344 | TERMINAL-RING (4-GA, 1/2-IN SCREW) | 1 | |
| 4842561 | 10 CABLE AS (RELAY) | 1 | |
| 9G4343 | TERMINAL-RING (4-GA, 1/4-IN SCREW) | 1 | |
| 5P3454 | TERMINAL-RING (4-GA, 5/16-IN SCREW) | 1 | |
| 1305300 | 11 CLIP | 1 | |
| 1772215 | 12 STRAP-DUAL CLAMP | 4 | |
| 2042281 | 13 STRAP-CABLE | 1 | |
| 3445673 | 14 NUT (M6X1-THD) | 1 | |
| 3812621 | 15 MOUNTING-CABLE TIE | 1 | |
| 5C2874 | 16 NUT (M5X0.8-THD) | 1 | |
| 5P4115 | 17 WASHER-HARD (7.2X19X2-MM THK) | 4 | |
| 8T0328 | 18 WASHER-HARD (5.5X10X1-MM THK) | 1 | |
| 8T4138 | 19 BOLT (M6X1X20-MM) | 1 | |
| 8T4970 | 20 BOLT (M6X1X14-MM) | 2 | |
| 9X2044 | 21 SCREW-TRUSS HEAD (M6X1X16-MM) | 1 |
