Assembly
100%

479-1687 WIRING GP-ELECTRONIC CONTROLPART OF 473-2856 ELECTRICAL AR

Group No: 479-1687
Part NumberPart NameQty
7K11811 STRAP-CABLE15
8T87992 BOOT (RED)6
8T96553 MOUNT-ISOLATION24
10803584 FLASHER AS (24-VOLT)(TURN SIGNAL)1
24183675 SWITCH AS-MAGNETIC (12-VOLT)(MAIN RELAY)1
4F2294NUT-JAM (5/16-24-THD)2
8T8730SOCKET-CONNECTOR (16-GA TO 20-GA)2
1552270KIT-CONNECTING PLUG (2-PIN)1
45595806 CONTROL GP-UNPROGRAMMED (ELECTRONIC)3
37584027 RELAY AS (12-VOLT)(ENGINE ECM)1
37584027A RELAY AS (12-VOLT)(GLOW PLUG RELAY)1
46178478 PLATE AS1
6V9632NUT-WELD (M6X1-THD)6
7T1099LINK6
8T3490NUT-WELD (M10X1.5-THD)3
8T3612NUT-WELD (M8X1.25-THD)5
1788510PLATE-WELD1
46789859 PLATE1
516678810 HARNESS AS-CONTROL1
096616611 WASHER-HARD (4.5X9X1-MM THK)16
099237412 BOLT-SOCKET HEAD (M5X0.8X12-MM)4
130530013 CLIP17
132578914 CLIP (LADDER)5
133693415 SPACER (11X20X25-MM THK)7
177221516 STRAP-DUAL CLAMP6
1H324417 LOCKWASHER4
344567418 NUT (M8X1.25-THD)2
4P758119 CLIP (LADDER)1
5C287420 NUT (M5X0.8-THD)1
5C289021 NUT (M6X1-THD)4
5C726122 NUT (M8X1.25-THD)16
5C831223 NUT (M4X0.7-THD)8
5C955324 BOLT (M6X1X16-MM)4
5P411625 WASHER-HARD (8.8X20.5X2-MM THK)12
5P716226 SCREW-MACHINE (10-32X0.5-IN)4
6I141827 SPACER (8.2X12.7X28.7-MM THK)12
6V967228 SCREW-MACHINE (M4X0.7X16-MM)8
7R793929 CLAMP-PIPE12
7R795130 PLATE6
7X253531 BOLT (M6X1X60-MM)12
8T032832 WASHER-HARD (5.5X10X1-MM THK)1
8T412133 WASHER-HARD (11X21X2.5-MM THK)3
8T413834 BOLT (M6X1X20-MM)6
8T418635 BOLT (M10X1.5X40-MM)1
8T418936 BOLT (M8X1.25X20-MM)2
8T419137 BOLT (M10X1.5X16-MM)6
8T419838 BOLT (M10X1.5X100-MM)2
8T420539 WASHER-HARD (7.2X14.5X2-MM THK)8
8T422240 WASHER-PLATED (11X32X2.5-MM THK)6
8T422441 WASHER-HARD (8.8X16X2-MM THK)7
8T490842 BOLT (M8X1.25X25-MM)1
9X825643 WASHER (6.6X12X2-MM THK)6
7X060844 WASHER-HARD (10.2X16X2-MM THK)2
9F564445 LOCKWASHER2
