System And Components
498-1486 PUMP GP-PISTONPART OF 475-6744 PUMP GP-PISTON
Group No: 498-1486
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 2666926 | 1 ORIFICE | 1 | |
| 3956637 | 2 SCREW-LOCK | 1 | |
| 3233728 | 3 SCREW-FLAT HEAD (M8X1.25X14-MM) | 1 | |
| 9S8004 | 4 PLUG (9/16-18-THD) | 2 | |
| 3J1907 | 5 SEAL-O-RING | 2 | |
| 3956639 | 6 SCREW-LOCK | 1 | |
| 9S8002 | 7 PLUG (7/16-20-THD) | 4 | |
| 3J7354 | 8 SEAL-O-RING | 4 | |
| 1204394 | 9 PLUG-BREAK OFF | 2 | |
| 9S8008 | 10 PLUG (1-1/16-12-THD) | 2 | |
| 3D2824 | 11 SEAL-O-RING | 2 | |
| 9S8005 | 12 PLUG (3/4-16-THD) | 2 | |
| 3K0360 | 13 SEAL-O-RING | 2 | |
| 3960094 | 14 PIN | 2 | |
| 1776949 | 15 ACTUATOR GP-PUMP | 1 | |
| 2064881 | 16 PLUG-ORIFICE | 2 | |
| 4981484 | 17 VALVE GP-PUMP CONTROL | 1 | |
| 4981487 | 18 COVER | 1 | |
| 1053488 | 19 BOLT-SOCKET HEAD (M10X1.5X16-MM) | 2 | |
| 1956948 | 20 WASHER (10X13X1-MM THK) | 2 | |
| 4981490 | 21 PUMP GP-PISTON | 1 | |
| 4981489 | 22 HEAD GP-PUMP | 1 | |
| 1229718 | 23 PIN | 1 | |
| 4510464 | 24 PLUG | 1 | |
| 1878001 | 25 SEAL | 1 | |
| 4981488 | 26 ROTATING GP-PUMP | 1 | |
| 6E4350 | 27 PIN | 1 | |
| 6E4240 | 28 NUT-SEALING (M10X1-THD) | 1 | |
| 1G3180 | 29 SCREW-ECCENTRIC | 1 |
