System And Components
476-5799 TANK GP-HYDRAULIC105-LITERS (27.74 US GAL)
Group No: 476-5799
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 5D7927 | 1 STRAINER AS-OIL (HYDRAULIC TANK) | 1 | |
| 5F3488 | END-STRAINER | 1 | |
| 9M7394 | 2 LEVER | 1 | |
| 1G7663 | 3 STRAINER AS (HYDRAULIC TANK) | 1 | |
| 0304606 | SEAL-O-RING | 1 | |
| 2D4202 | 4 PLATE | 1 | |
| 5D1911 | 5 COVER-HYDRAULIC CAP | 1 | |
| 7H1447 | 6 CAP-FILLER (HYDRAULIC OIL) | 1 | |
| 1097411 | 7 SEAL-O-RING | 1 | |
| 1837264 | 8 VALVE AS-FLUID SAMPLING (HYDRAULIC OIL) | 1 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 2655644 | 9 GAUGE GP-SIGHT (HYDRAULIC TANK) | 1 | |
| 3078353 | 10 COVER | 1 | |
| 3400508 | 11 SENSOR GP-TEMPERATURE (HYDRAULIC OIL) | 1 | |
| 2385080 | SEAL-O-RING | 1 | |
| 2566453 | SENSOR-TEMPERATURE (2-PIN)(HYDRAULIC OIL) | 1 | |
| 4589755 | 12 SWITCH AS-PRESSURE (HYDRAULIC OIL) | 1 | |
| 4765798 | 13 TANK AS-HYDRAULIC | 1 | |
| 4854600 | 14 FILTER ELEMENT AS-OIL (HYDRAULIC TANK) | 1 | |
| 4227912 | FILTER (HYDRAULIC TANK) | 1 | |
| 1809933 | 15 ADAPTER AS | 1 | |
| 3J7354 | SEAL-O-RING | 1 | |
| 1359941 | ADAPTER | 1 | |
| 1L5072 | 16 DOWEL | 1 | |
| 3J7354 | 17 SEAL-O-RING | 1 | |
| 6H9361 | 18 RING-RETAINING | 1 | |
| 8C3451 | 19 CAP-DUST (HYDRAULIC OIL) | 1 | |
| 8T2275 | 20 BALL | 1 | |
| 8T4121 | 21 WASHER-HARD (11X21X2.5-MM THK) | 4 | |
| 8T4136 | 22 BOLT (M10X1.5X25-MM) | 4 | |
| 8T4192 | 23 BOLT (M12X1.75X25-MM) | 6 | |
| 8T4223 | 24 WASHER-HARD (13.5X25.5X3-MM THK) | 6 | |
| 9H6454 | 25 GASKET (HYDRAULIC TANK FILL CAP) | 1 | |
| 9S4182 | 26 PLUG (7/16-20-THD) | 1 | |
| 2J7761 | 27 RING-RETAINING | 1 |
