System And Components
477-1827 VALVE & MOUNTING GPPART OF 477-1808 HYDRAULIC AR-AUXILIARY
Group No: 477-1827
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 8I3633 | 1 ADAPTER AS | 2 | |
| 6V8397 | SEAL-O-RING | 1 | |
| 1626816 | SEAL | 1 | |
| 3866212 | ADAPTER | 1 | |
| 1505968 | 2 TEE AS | 4 | |
| 4J5477 | SEAL-O-RING | 2 | |
| 6V9835 | TEE | 1 | |
| 1705121 | 3 ADAPTER AS | 2 | |
| 4J5477 | SEAL-O-RING | 1 | |
| 1626816 | SEAL | 1 | |
| 3779597 | ADAPTER | 1 | |
| 2935320 | 4 VALVE | 1 | |
| 2938696 | 5 VALVE AS-SOLENOID (BRAKE) | 2 | |
| 2948408 | 6 TEE AS | 1 | |
| 4J5477 | SEAL-O-RING | 1 | |
| 2948409 | TEE | 1 | |
| 4754768 | 7 SWITCH AS-PRESSURE (AUXILIARY) | 1 | |
| 5241089 | 8 PLATE AS | 1 | |
| 1203956 | 9 BOLT-SOCKET HEAD (M5X0.8X60-MM) | 2 | |
| 1488351 | 10 ELBOW AS | 1 | |
| 4J5477 | SEAL-O-RING | 1 | |
| 6V9849 | ELBOW | 1 | |
| 1504047 | 11 ADAPTER AS | 1 | |
| 3J7354 | SEAL-O-RING | 1 | |
| 8T2353 | ADAPTER | 1 | |
| 1645567 | 12 COUPLER AS-QUICK DISCONNECT (MALE) | 1 | |
| 6V3965 | FITTING (QUICK DISCONNECT) | 1 | |
| 2147568 | SEAL-O-RING | 1 | |
| 3133480 | 13 ELBOW AS | 5 | |
| 4J5477 | SEAL-O-RING | 1 | |
| 4J9535 | SEAL-O-RING | 1 | |
| 2815959 | RING-RETAINING | 1 | |
| 3133479 | ELBOW | 1 | |
| 3445673 | 14 NUT (M6X1-THD) | 2 | |
| 3T0851 | 15 LOCKNUT (M5X0.8-THD) | 2 | |
| 6V0405 | 16 SEAL-BONDED | 1 | |
| 7X7729 | 17 WASHER (11X25X3-MM THK) | 3 | |
| 6V0852 | 18 CAP-DUST | 1 | |
| 8T0328 | 19 WASHER-HARD (5.5X10X1-MM THK) | 2 | |
| 8T2396 | 20 BOLT (M6X1X60-MM) | 2 | |
| 8T4195 | 21 BOLT (M10X1.5X30-MM) | 3 | |
| 9X8256 | 22 WASHER (6.6X12X2-MM THK) | 4 | |
| 2115255 | 23 BOLT-SOCKET HEAD (M5X0.8X55-MM) | 2 |
