System And Components
444-5442 CANOPY GPAN ATTACHMENT
Group No: 444-5442
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 5P7958 | 1 SLEEVE-CABLE SPLICE | 2 | |
| 8I3633 | 2 ADAPTER AS | 2 | |
| 6V8397 | SEAL-O-RING | 1 | |
| 1626816 | SEAL | 1 | |
| 3866212 | ADAPTER | 1 | |
| 0860507 | 3 PIN | 1 | |
| 2690194 | 4 FILM-WARNING (CRUSH HAZARD, STAY BACK, U.S.) | 1 | |
| 3033427 | 5 FILM-IDENTIFICATION (CAT) | 1 | |
| 4223788 | 6 CANOPY GP (TOP) | 1 | |
| 5235161 | 7 BLOCK | 4 | |
| 4436854 | 8 PIN AS | 1 | |
| 9X8257 | WASHER (17.5X30X3.5-MM THK) | 1 | |
| 4436855 | 9 SPACER (7X10X15-MM THK) | 4 | |
| 4483798 | 10 CYLINDER GP-HYDRAULIC (MOUNTING) | 1 | |
| 4J5477 | SEAL-O-RING | 2 | |
| 2004635 | ELBOW | 2 | |
| 4538819 | CYLINDER AS-HYDRAULIC | 1 | |
| 4538822 | 11 SUPPORT AS | 1 | |
| 4538823 | 12 SUPPORT | 2 | |
| 4538829 | 13 CORD | 1 | |
| 5162000 | 14 FLOOR AS | 1 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 3 | |
| 4538901 | 15 WIRING GP-CANOPY (RISER) | 1 | |
| 4692232 | 16 PLATE-SUPPORT | 1 | |
| 4764234 | 17 HOSE AS | 1 | |
| 4764236 | 18 HOSE AS | 1 | |
| 5358853 | 19 PUMP GP-ELECTRIC DRIVE | 1 | |
| 4784124 | 20 PLATE | 1 | |
| 4784128 | 21 SPACER | 1 | |
| 4784129 | 22 COVER | 1 | |
| 4784138 | 23 WIRING GP-CANOPY | 1 | |
| 0951270 | 24 SETSCREW-SOCKET (M12X1.75X30-MM) | 8 | |
| 1566175 | 25 CLIP (LADDER) | 2 | |
| 1748131 | 26 SCREW-TRUSS HEAD (M4X0.7X12-MM) | 6 | |
| 1772215 | 27 STRAP-DUAL CLAMP | 2 | |
| 3445674 | 28 NUT (M8X1.25-THD) | 6 | |
| 3445675 | 29 NUT (M10X1.5-THD) | 2 | |
| 3514318 | 30 CLIP (LOOP) | 1 | |
| 5P4116 | 31 WASHER-HARD (8.8X20.5X2-MM THK) | 8 | |
| 5P7957 | 32 LANYARD | 2 | |
| 6V7688 | 33 LOCKNUT (M20X2.5-THD) | 2 | |
| 6V7743 | 34 LOCKNUT (M6X1-THD) | 10 | |
| 6V9167 | 35 BOLT (M20X2.5X140-MM) | 2 | |
| 7X0515 | 36 WASHER-HARD (17X35X5-MM THK) | 6 | |
| 7X7729 | 37 WASHER (11X25X3-MM THK) | 6 | |
| 8C6802 | 38 SCREW-FLAT HEAD (M6X1X3.72-MM) | 4 | |
| 8T4121 | 39 WASHER-HARD (11X21X2.5-MM THK) | 5 | |
| 8T4122 | 40 WASHER-HARD (17X32X3.5-MM THK) | 10 | |
| 8T4123 | 41 WASHER (22X35X3.5-MM THK) | 4 | |
| 8T4132 | 42 NUT (M16X2-THD) | 7 | |
| 8T4136 | 43 BOLT (M10X1.5X25-MM) | 3 | |
| 8T4137 | 44 BOLT (M10X1.5X20-MM) | 2 | |
| 8T4140 | 45 BOLT (M16X2X60-MM) | 6 | |
| 8T4171 | 46 BOLT (M6X1X12-MM) | 1 | |
| 8T4189 | 47 BOLT (M8X1.25X20-MM) | 2 | |
| 8T4195 | 48 BOLT (M10X1.5X30-MM) | 1 | |
| 8T4196 | 49 BOLT (M10X1.5X35-MM) | 2 | |
| 8T4223 | 50 WASHER-HARD (13.5X25.5X3-MM THK) | 2 | |
| 8T4244 | 51 NUT (M12X1.75-THD) | 8 | |
| 8T4779 | 52 BOLT (M16X2X35-MM) | 5 | |
| 8T4908 | 53 BOLT (M8X1.25X25-MM) | 4 | |
| 8T5001 | 54 BOLT (M12X1.75X130-MM) | 1 | |
| 8T8549 | 55 LOCKNUT (M12X1.75-THD) | 1 | |
| 5010566 | 56 FILM-IDENTIFICATION (LOWER) | 1 | |
| 8T4186 | 57 BOLT (M10X1.5X40-MM) | 1 | |
| 9X6155 | 58 BOLT-SOCKET HEAD (M6X1X16.7-MM) | 6 | |
| 9X8256 | 59 WASHER (6.6X12X2-MM THK) | 11 | |
| 5160334 | 60 PLATE | 1 | |
| 8T4200 | 61 BOLT (M8X1.25X16-MM) | 2 | |
| 8T4224 | 62 WASHER-HARD (8.8X16X2-MM THK) | 6 | |
| 4951484 | KIT-SEAL | 1 |
